NEW 14.5m Timber Fishing Trawler


Price
NZ $1,850,000 Indicative price
Currency
Length
47' 7" - 14.50m
Use
Off-shore Fishing, Commercial
Vessel Location
New Zealand
Model Year
2022
Hull Material
Timber

We are keen sellers and would love to see this vessel go to someone who could put their name on it from day 1, creating a fantastic legacy for their business, family, it deserves a good home, if not then we may fish it - but unfortunately this is subject to our selling some vessels to rationalise our fleet - we just have too many top quality modern fishing boats, meaning we don't have enough quota, skippers or crew - oh and then there is the financial resources - so were keen sellers.

SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.


Price
NZ $1,850,000 Indicative price
Boat Reference
3999
Model Year
2022
Length
47' 7" - 14.50m
Beam
4.84m (15ft 10in)m
Draft
2.3m (7ft 6in)m
Displacement
57 tonnes Tonnes
Vessel Location
New Zealand
Region
South Pacific
Builder
Stark Bros Ltd.
Hull Material
Timber
Engine
Main Engine: Scania D109 070M, 300hp @ 1800rpm Gearbox: Twin Disc MG-5091SC, 2.95:1 Propeller: 4 blade 40.5" AB2 Nickel Aluminium Bronze, Free Running Speed: 8 knots Hot Water Cylinder: 60 litres Lube Oil Capacity: 500 litres Waste Water Capacity: 105 litres Hydraulic Oil Capacity: - litres
Engine Make
Scania
Horsepower
300
Genset
Kohler 20EFOZD, 20kva
Fuel
4400 liters
Water
250 liters
Accommodation
Crew: 3
Toilet
Sealand 8100 series 24v
Refrigeration
DWM 3.0HP Compressor Shell/Tube Condenser
Electrics
Electrical: Multiplus 24/3000/70-16 230v AC Inverter /charger
Electronics / Navigation
Steering: Hydraulic 2.5" Marine Rams of 225mm stroke
Stabilisers: Stark Bros Wings Port/Stbd
Deck Gear
Equipment
Trawl Winches: 2 x Stark Bros Hydraulic with HMB125 Staffa hyd motors
Net Rollers: Stark Bros - 1 x Main, with HMB 125 Staffa hyd motor
Anchor Winch: Lofrans Titan 24v with 14mm chain
Survey Details
-Engine Commissioning was completed on 28.03.2022 by Scania technicians from Wellington.
Sea trials were completed on Tuesday 29.03.2022 - again with technicians from Scania.
In Survey to: NZ Coastal Fishing Vessel
Survey Company: SGSM&I
Remarks
-When completed, Departure Displacement is estimated at 57 tonnes
-Fish Hold is 26m3, and will hold ~288 standard plastic bins ( 800mm x 430mm nested height 200mm )

-Due to our heavy external workload, we have undertaken work on the vessel only as resources allowed since it was put in the water back in September 2021.
The draft stability test was completed and we have now installed the final lead ballast, with the final stability test and then the final Stability Booklet to be produced in coming months.

-Bollard Pull testing was completed on 11.04.2022
Achieved 2,900 kg at 1635 rpm 100% load
Scania have confirmed the engine has full power from 1400rpm to 1800rpm so they are happy with 100% load at 1635 rpm.
This will essentially provide better fuel consumption by giving better speed and tow at a lower rpm, so is a good thing.

We ( Stark Bros Ltd ) designed and built this traditional inshore 14.5m Timber Trawler as a spec project to smooth our variable ship repair workload over the years, traditionally we have always had a timber vessel under construction - sadly this will be our last commercial Timber Fishing Vessel with no plans to build another spec vessel given the likely requirements for future vessels will more likely see larger steel vessels such as our FV Legacy / FV Endeavour, etc.

As with our other vessels we designed and built this vessel for sale, but also perhaps expecting it to be in our own long term ownership / use as for other spec vessels - so we build them to a high quality and because our main business is ship repair, we build them to be as efficient as possible in regards to maintenance, to try and reduce the long term cost of ownership.

Our fishing company catches Fresh Market Fish for local restaurant / export and also some low value bulk fish for factory processing.
This vessel is fitted with a refrigerated fish hold, with conveyors for fish handling / sorting from the main fish pound - allowing efficient transfer of fish to the refrigerated hold using less people.

We therefore provide you the following and attached information on the BRAND NEW 14.5m Timber Fishing Trawler.

We include our current indicative asking prices as below - but we are open to negotiation.
