NEW 20m Crew Boat
Price
US $1,510,500 Available to order
Currency
Length
65' 7" - 19.98m
Vessel Location
UAE
Model Year
New
Hull Material
Aluminium
Type: Crew Boat (IACS Class). Passenger Capacity: 18 person. Crew: 6 person. Main Engine: 2x Weichai, WP12C500-18, kW 368, rpm 1800. Laiden Cruise Speed: 15 knots.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Price
US $1,510,500 Available to order
Vessel Name
Built to order
Boat Reference
5774
Model Year
New
Length
65' 7" - 19.98m
Beam
5.6m (18ft 4in)
Draft
1.6m (5ft 2in)
Displacement
Tonnes
Vessel Location
Uae
Region
Africa and Middle East
Use
Cruising
Hull Material
Aluminium
Engine
PROPULSION
Main Engine: 2x Weichai, WP12C500-18, kW 368, rpm 1800
Reduction Gearbox: 2x Advance, Model: HC300, Ratio 2.23:1
Stern Gear Design: 1x Design of Propeller, Rudder and Shafting arrangement
Laiden Cruise Speed: 15 knots
Number Engines
2
Fuel Type
Diesel
Max Speed
Speed: 15 knots
Propulsion
None
Accommodation
Passenger Capacity: 18 person
Crew: 6 person
Crew: 6 person
Ground Tackle
Anchor, Anchor Chain and Winch: 1x Anchor weight: 48 Kgs, Studless, Chain Dia: 8mm, Chain lengths: 82.5m, Proof load: 24kN, Breaking load: 48kN, Windlass continuous duty pull: 3.06kN
Mooring Ropes: 7x Design brake force: 78.75T, Dia:18mm, Breaking strength: 85.7T
Tyre Fenders: 32x Dia 700mm
Mooring Ropes: 7x Design brake force: 78.75T, Dia:18mm, Breaking strength: 85.7T
Tyre Fenders: 32x Dia 700mm
Safety Gear
LSA & FFA
Multiple loose items: Set, As per Fire control & Safety plan
Fire detection and alarm System: 1 Set, As per Fire control & Safety plan
Aerosol Fire Suppression System: 1 Set, As per Gross volume of E/R
Potable Fire Pump: 1x 25 m3/hr @ 2.5 bar, Portable Centrifugal Type with Self Priming Unit
Multiple loose items: Set, As per Fire control & Safety plan
Fire detection and alarm System: 1 Set, As per Fire control & Safety plan
Aerosol Fire Suppression System: 1 Set, As per Gross volume of E/R
Potable Fire Pump: 1x 25 m3/hr @ 2.5 bar, Portable Centrifugal Type with Self Priming Unit
Electrics
POWER
Diesel Generator: 2x Weichai, WP2.3D40E200 Engine with Shanghai Stamford CCFJ30J-H Alternator, Sea water cooled, 30 kW, 415 V, 3 Ph, 50 Hz
MSB: 1x Switch board panel with Voltmeter, kW meter, Frequency meter, Ammeter, Insulation meter, Breakers and accessories
Battery Charger: Victron TG24/30A Battery Charger
Battery: 2x 12V 200AH Battery for GMDSS equipment
Diesel Generator: 2x Weichai, WP2.3D40E200 Engine with Shanghai Stamford CCFJ30J-H Alternator, Sea water cooled, 30 kW, 415 V, 3 Ph, 50 Hz
MSB: 1x Switch board panel with Voltmeter, kW meter, Frequency meter, Ammeter, Insulation meter, Breakers and accessories
Battery Charger: Victron TG24/30A Battery Charger
Battery: 2x 12V 200AH Battery for GMDSS equipment
Electronics / Navigation
Navigation & Communication
Radar: 1x Onwa, KR-1008,32NM
GPS: 1x Onwa, KP-27
MFHF Complete Set: 1x CETC WT-6000 MFHF SSB Radio
PA System: 1x Intercom for Bridge and Cabins with Amplifier and Horn Speaker
Air Horn: 1x Marco 24V 10Amp Electric Air Horn System
Magnetic Compass: 1x Iluminated YQ-50F
Navigation Lights: 1x Navigation Light Panel (8CH)
AIS: 1x EM Track A 200 Class A
Portable VHF: 1x Marinelite Class A DSC VHF, Model VHF9000
EPIRB: 1x AIS EPIRB, Model-VEP8A
SART: 1x AIS SART S9000
Navtex Receiver: 1x CETC ME1701
Radar: 1x Onwa, KR-1008,32NM
GPS: 1x Onwa, KP-27
MFHF Complete Set: 1x CETC WT-6000 MFHF SSB Radio
PA System: 1x Intercom for Bridge and Cabins with Amplifier and Horn Speaker
Air Horn: 1x Marco 24V 10Amp Electric Air Horn System
Magnetic Compass: 1x Iluminated YQ-50F
Navigation Lights: 1x Navigation Light Panel (8CH)
AIS: 1x EM Track A 200 Class A
Portable VHF: 1x Marinelite Class A DSC VHF, Model VHF9000
EPIRB: 1x AIS EPIRB, Model-VEP8A
SART: 1x AIS SART S9000
Navtex Receiver: 1x CETC ME1701
Remarks
Type: Crew Boat (IACS Class)
Depth: 02.60 m
Freeboard: 01.00 m
PLATING THICKNESS & CAPACITY
Sides, Bulkheads: 6mm (5083 Aluminium plates)
Keel: 8mm (5083 Aluminium plates)
Deck: 6mm (5083 Aluminium plates)
Cabin: 6mm (5083 Aluminium plates)
Transom: 8mm (5083 Aluminium plates)
Transverse Sections: 6mm (5083 Aluminium plates)
Stern Gear:
2x Propeller - NIAL-Cu3,36" Dia, 4 Blades
Propeller Shaft Assembly, Dia 70 mm, F51 Duplex Steel
Stern Tube Assembly, Dia 152.4 mm x 3000 mm Long
P Bkt, NIAL-CU3,40 x 250 x 1200 mm
Stern Tube Seals & Bearings: 2x Stern Tube Seal, Stern Tube Bearing and P Bkt Bearings
Engine throttle control system: 1x Kings Control KC 200 - H200 Dual Type Fixed Engine Control Head with A200 Mechanical Actuators
Steering Gear: Electro Hydraulic
Rudder: 2x Single Blade Spade Rudder, NIAL-CU3,520 x 900mm
Deck Outfitting
Doors: 3, As per Design
Windows: 11, As per Design
Scuttles: As per Design
Hatches: As per Design
Bollard: As per Design
Fair lead / Chocks: As per Design
Miscellaneous Equipment
STP: 1x Marine Sewage Treatment Plant, For 10 persons, Model: HBNA-10, Supply: 380V 50Hz 3Phase
ER Fresh Air and Exhaust Blowers: 4x Exhaust fan, 9000 CMH, 150Pa, 1.5kW, 1440rpm, 2 sets
Air Vents: As per design
Batteries: As per design
AC Systems: 1 Lot, Split AC for Passenger area x 1, Split AC for Wheelhouse x, VRF unit with 1 outdoor and 3 indoor units for Crew accommodation
Pilot Chair: 1x Luxury, Non-reclining
Passenger Chairs: 19 Luxury, non-reclining
Interior work: 1 Lot: Passenger Area + Wheelhouse+ Crew Accommodation area + Pantry
Toilet: Bulkhead panelling, Flooring, Ceiling, Lighting, Sanitary ware, Plumbing, Bedding, Furniture, Fridge, Hotplate etc.
Insulation Work: 1 Lot: 50mm wool insulation supply and fixing in Passenger Area, Wheelhouse, Crew Accommodation area, Pantry, Toilet
Paints
Paints: 1 Lot, International paint scheme for 5 years service life
Surface preparation and Paint application: 1 Lot, Full masking and protection of
surrounding areas, full surface preparation by sanding & cleaning. Apply one primer coat, one anti-
corrosive cost and one final coat. Wash down of all painted area.
Pipe & Fittings
CS Galvanized: 1 Lot, As per design
Aluminium: 1 Lot, As per design
Valves and Others
Valves and Instruments: 1 Lot, As per design
Anodes: Hull anodes: 1 Lot, As per design
Engine Accessories: Wet exhaust system: 4 As per design
Distribution Panels: 12x Start / Stop local control panels for:
* FO transfer pump x 1
* Bilge, fire and ballast pumps x 2
* FW hydrophore skid x 1
* STP x 1
* AC Units x 3
* ER blowers x 4
PUMPS
Fuel Oil Transfer Pump with Motor: 1x 5 m3/hr @ 2 bar, Gear / Screw Type
Fire, Bilge & Ballast Pump with Motor: 2x 25 m3/hr @ 3 bar, Centrifugal Type with Self-Priming Unit
Lube Oil Hand Pump: 1x 2 m3/hr @ 2 bar, Semi-Rotary Type
Sewage Pump with Motor: 1x 5 m3/hr @ 4 bar, Centrifugal Type
Oily Water Hand Pump: 1x 4 m3/hr @ 2 bar, Semi-Rotary Type
Fresh Water Pump with Motor: 1x 3 m3/hr @ 5 bar, Centrifugal Type
Freshwater Hydrophore Skid: 1x Pump Capacity: 1 m3/hr @ 2 bar x 2 Nos, Hydrophore Tank: 100L, With Air Compressor
Fresh Water Cargo Tank Pump: 1x 5 m³/hr at 5 bar, Centrifugal Type
Emergenc
Depth: 02.60 m
Freeboard: 01.00 m
PLATING THICKNESS & CAPACITY
Sides, Bulkheads: 6mm (5083 Aluminium plates)
Keel: 8mm (5083 Aluminium plates)
Deck: 6mm (5083 Aluminium plates)
Cabin: 6mm (5083 Aluminium plates)
Transom: 8mm (5083 Aluminium plates)
Transverse Sections: 6mm (5083 Aluminium plates)
Stern Gear:
2x Propeller - NIAL-Cu3,36" Dia, 4 Blades
Propeller Shaft Assembly, Dia 70 mm, F51 Duplex Steel
Stern Tube Assembly, Dia 152.4 mm x 3000 mm Long
P Bkt, NIAL-CU3,40 x 250 x 1200 mm
Stern Tube Seals & Bearings: 2x Stern Tube Seal, Stern Tube Bearing and P Bkt Bearings
Engine throttle control system: 1x Kings Control KC 200 - H200 Dual Type Fixed Engine Control Head with A200 Mechanical Actuators
Steering Gear: Electro Hydraulic
Rudder: 2x Single Blade Spade Rudder, NIAL-CU3,520 x 900mm
Deck Outfitting
Doors: 3, As per Design
Windows: 11, As per Design
Scuttles: As per Design
Hatches: As per Design
Bollard: As per Design
Fair lead / Chocks: As per Design
Miscellaneous Equipment
STP: 1x Marine Sewage Treatment Plant, For 10 persons, Model: HBNA-10, Supply: 380V 50Hz 3Phase
ER Fresh Air and Exhaust Blowers: 4x Exhaust fan, 9000 CMH, 150Pa, 1.5kW, 1440rpm, 2 sets
Air Vents: As per design
Batteries: As per design
AC Systems: 1 Lot, Split AC for Passenger area x 1, Split AC for Wheelhouse x, VRF unit with 1 outdoor and 3 indoor units for Crew accommodation
Pilot Chair: 1x Luxury, Non-reclining
Passenger Chairs: 19 Luxury, non-reclining
Interior work: 1 Lot: Passenger Area + Wheelhouse+ Crew Accommodation area + Pantry
Toilet: Bulkhead panelling, Flooring, Ceiling, Lighting, Sanitary ware, Plumbing, Bedding, Furniture, Fridge, Hotplate etc.
Insulation Work: 1 Lot: 50mm wool insulation supply and fixing in Passenger Area, Wheelhouse, Crew Accommodation area, Pantry, Toilet
Paints
Paints: 1 Lot, International paint scheme for 5 years service life
Surface preparation and Paint application: 1 Lot, Full masking and protection of
surrounding areas, full surface preparation by sanding & cleaning. Apply one primer coat, one anti-
corrosive cost and one final coat. Wash down of all painted area.
Pipe & Fittings
CS Galvanized: 1 Lot, As per design
Aluminium: 1 Lot, As per design
Valves and Others
Valves and Instruments: 1 Lot, As per design
Anodes: Hull anodes: 1 Lot, As per design
Engine Accessories: Wet exhaust system: 4 As per design
Distribution Panels: 12x Start / Stop local control panels for:
* FO transfer pump x 1
* Bilge, fire and ballast pumps x 2
* FW hydrophore skid x 1
* STP x 1
* AC Units x 3
* ER blowers x 4
PUMPS
Fuel Oil Transfer Pump with Motor: 1x 5 m3/hr @ 2 bar, Gear / Screw Type
Fire, Bilge & Ballast Pump with Motor: 2x 25 m3/hr @ 3 bar, Centrifugal Type with Self-Priming Unit
Lube Oil Hand Pump: 1x 2 m3/hr @ 2 bar, Semi-Rotary Type
Sewage Pump with Motor: 1x 5 m3/hr @ 4 bar, Centrifugal Type
Oily Water Hand Pump: 1x 4 m3/hr @ 2 bar, Semi-Rotary Type
Fresh Water Pump with Motor: 1x 3 m3/hr @ 5 bar, Centrifugal Type
Freshwater Hydrophore Skid: 1x Pump Capacity: 1 m3/hr @ 2 bar x 2 Nos, Hydrophore Tank: 100L, With Air Compressor
Fresh Water Cargo Tank Pump: 1x 5 m³/hr at 5 bar, Centrifugal Type
Emergenc
