NEW 23.9m Multipurpose Work Boat for Sale
Currency
Length
78' 5" - 23.90m
Vessel Location
Turkey
Model Year
New
Hull Material
Steel
Navigation notation: Coastal Area. Speed: 9 Knots. Engine Power: 2 x 550 HP. The accommodation area has 4 (four) cabins. Deck Load: 10 T/M2 FRIO-13 / 4 T/M2 Other.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Boat Reference
5084
Model Year
New
Length
78' 5" - 23.90m
Beam
9.20m (30ft 2.25in)
Draft
2.25m (7ft 4.60in)
Displacement
Tonnes
Vessel Location
Turkey
Region
Europe
Use
Commercial
Hull Material
Steel
Number Engines
2
Horsepower
2 x 550 HP
Cruise Speed
9 Knots
Genset
Gen. Set: 2 x 77 kVA
Accommodation
Number of Crew: 3/4/5 (three or four or five)
CABINS AND MESS ROOM
The accommodation will be arranged as shown on the GA
The accommodation area has 4 (four) cabins
1 (one) single cabin for the master,
1 (one) single cabin for the chief engineer,
1 (one) single cabin for 1 (one) crew
1 (one) double cabin for 2 (two) crew
2 (two) wet unit with shower to be installed at accommodation area as per GA.
All sleeping cabins will be separated by a wall with a door. Bed's size is to be about 85 x 200cm.
All the above will be proper insulated from the hull and provided with air condition.
Also, there will be a mess room for personnel with a pantry.
All cabins & mess to be provided with TV antenna sockets
Flooring will be from non-slip marine mat.
CABINS AND MESS ROOM
The accommodation will be arranged as shown on the GA
The accommodation area has 4 (four) cabins
1 (one) single cabin for the master,
1 (one) single cabin for the chief engineer,
1 (one) single cabin for 1 (one) crew
1 (one) double cabin for 2 (two) crew
2 (two) wet unit with shower to be installed at accommodation area as per GA.
All sleeping cabins will be separated by a wall with a door. Bed's size is to be about 85 x 200cm.
All the above will be proper insulated from the hull and provided with air condition.
Also, there will be a mess room for personnel with a pantry.
All cabins & mess to be provided with TV antenna sockets
Flooring will be from non-slip marine mat.
Galley
PANTRY EQUIPMENT
The following equipment to be installed in the pantry. All will have the capacity for 6 (six) persons.
1. Electrical Baking Oven 1 (one)
2. Refrigerator 1 (one)
3. Dish Washing Machine 1 (one)
4. Coffee Machine 1 (one)
5. Sink with hot and cold-water tap 1 (one)
6. Induction Steel hob cooker with 2 (two) cooking places and with metal fixators in bad weather 1 (one)
The following equipment to be installed in the pantry. All will have the capacity for 6 (six) persons.
1. Electrical Baking Oven 1 (one)
2. Refrigerator 1 (one)
3. Dish Washing Machine 1 (one)
4. Coffee Machine 1 (one)
5. Sink with hot and cold-water tap 1 (one)
6. Induction Steel hob cooker with 2 (two) cooking places and with metal fixators in bad weather 1 (one)
Survey Details
Environment Conditions: Sea water, temperature range from 0 degree Celsius +40 Degree Celsius Air, Temperature range from 0 degree Celsius +40 Degree Celsius
Navigation notation: Coastal Area
Navigation notation: Coastal Area
Remarks
Length Over (LOA): 23.90m
LBP: 22.345m
Beam: 9.20m
Draft (for work): 1.90m
Draft (max): 2.25m
Depth: 3.150m
Deck Load: 10 T/M2 FRIO-13 / 4 T/M2 Other
TANK CAPACITIES
The major thank capacities are:
Marine DO: about 40 m3
Cargo FW: 2 X about 20 m3
Ballast Water: about 70 m3
LBP: 22.345m
Beam: 9.20m
Draft (for work): 1.90m
Draft (max): 2.25m
Depth: 3.150m
Deck Load: 10 T/M2 FRIO-13 / 4 T/M2 Other
TANK CAPACITIES
The major thank capacities are:
Marine DO: about 40 m3
Cargo FW: 2 X about 20 m3
Ballast Water: about 70 m3
