NEW 65m LCT - 3x units available
Length
213' 3" - 65.00m
Vessel Location
JiangSu, China
Model Year
2025
Hull Material
Steel
Container capacity : 79 TEUs. Dwt : 1900 Ton. Class : Rina. Complement : 22p. Main Engine : 2x Yanmar Japan. Attached photo of No. 3 unit just launched, ready for delivery July 2025. No. 4 unit can be delivered in Sept 2025. No. 5 unit can be delivered in Mar 2026 (pls note that M/E for no. 5 will be Mitsubishi, and 35 Ton crane can be installed if necessary)
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Boat Reference
5311
Model Year
2025
Length
213' 3" - 65.00m
Beam
16.00m (52ft 6in)
Draft
4.50m (14ft 10in)
Displacement
Tonnes
Vessel Location
Jiangsu, China
Region
Asia
Use
Commercial
Hull Material
Steel
Engine
Main Machinery
Main Engines: 2 x Yanmar Japan 6EY17W (749KW/1350rpm)
Gearboxes: 2 x Yanmar Japan YXH-500L (4.07)
Emergency Generator: 1 x Cummins (China License) 80kW @ 1500rpm, 415/3/50
Service Speed: 85%MCR ~ 10kn
Pumps & Pressure Systems
Fire / G. S. / Ballast Pumps: 2 x ~41 m³/h @ 50m head
Emergency Fire Pump: 1 x ~25 m³/h @ 45m head
Sewage Transfer Pump: 1 x ~5 m³/h @ 27m head
Fuel Oil Transfer Pump: 1 x ~12 m³/h @ 25m head
Fuel Oil Cargo Pump: 1 x Jiangsu Zhenhua, China ~153 m³/h @ 50m head
Fresh Water Cargo Pump: 1 x ~80 m³/h @ 51m head
Dirty Oil Transfer Pump: 1 x ~6 m³/h @ 30m head
A/C S. W. Cooling Pump: 2 x ~55 m³/h @ 35m head
Bilge Daily Pump: 2 x ~5 m³/h @ 40m head
Freshwater Pressure Set: 1 x 500L, 2 x 3m³/h @ 4 bar pumps (Wuhan Zhongzhou, China)
Seawater Pressure Set: 1 x 500L, 2 x 3m³/h @ 4 bar pumps (Wuhan Zhongzhou, China)
Container capacity : 79 TEUs
Ballast Water: 772 m3
Fresh Water : 456 m3
Fuel Oil: (domestic) 307 m3
Fuel Oil (cargo) 689 m3
Water Treatment
Fresh Water Generator: 1 x Zhuhai, China - 5t/day
Oily Water Separator: 1 x MTE, Korea - 15 ppm, 1.0 m³/h
Sewage Treatment Plant: 1 x Taiko (China License) - for 24 persons
Engine Make
Yanmar
Number Engines
2
Propulsion
Shafting, Rudders, Propellers: 1 Shipset x Dongtai Shunyang, China
Genset
2 x Cummins (China License) 150kW @ 1500rpm, 415/3/50
Accommodation
Heating & Cooling
Hot Water Calorifier: 1 x Wuhan Zhongzhou, China - 300L @ 4 bar, 8kW, with ~2m³/h @ 20m circulating pump
Fans: 2 x Qingdao Dehongli, China - 25,000 m³/h
Complement : 22p
Hot Water Calorifier: 1 x Wuhan Zhongzhou, China - 300L @ 4 bar, 8kW, with ~2m³/h @ 20m circulating pump
Fans: 2 x Qingdao Dehongli, China - 25,000 m³/h
Complement : 22p
Air-Con
1 Shipset x Jiangsu Jiatai, China - Bitzer condenser, ambient 50°C, 25,000 m³/h inlet
Ground Tackle
Anchor Windlass / Ramp Door Winch: 2 x Xinghua Kaiyuan, China - 6.2t @ 9m/min
Anchors: 2 x Anhui Maoding, China - As per class approval
Anchor Chains: 2 x Anhui Maoding, China - 440m total (16 shackles), 36mm dia., Grade 3 stud-link
Anchors: 2 x Anhui Maoding, China - As per class approval
Anchor Chains: 2 x Anhui Maoding, China - 440m total (16 shackles), 36mm dia., Grade 3 stud-link
Safety Gear
Safety & Options
CO? System: 1 x Wuhan Weili, China
Painting: 1 Shipset x International
ECDIS (Optional): 1 Set x Shanghai Boji, China
S-VDR (Optional): 1 Set x Shanghai Boji, China
CCTV (Optional): 1 Shipset x Nantong Fangzhou, China
H?S Gas Detection (Optional): 1 Shipset x Nanjing Sifu, China
Navitax with Printer (Optional): 1 Set x Shanghai Boji, China
Life-Saving Equipment
Rescue Boat & Davit: 1 x Taizhou Kailun, China - Inboard Diesel Engine Type
Life-Saving Miscellaneous: 1 Shipset x China
CO? System: 1 x Wuhan Weili, China
Painting: 1 Shipset x International
ECDIS (Optional): 1 Set x Shanghai Boji, China
S-VDR (Optional): 1 Set x Shanghai Boji, China
CCTV (Optional): 1 Shipset x Nantong Fangzhou, China
H?S Gas Detection (Optional): 1 Shipset x Nanjing Sifu, China
Navitax with Printer (Optional): 1 Set x Shanghai Boji, China
Life-Saving Equipment
Rescue Boat & Davit: 1 x Taizhou Kailun, China - Inboard Diesel Engine Type
Life-Saving Miscellaneous: 1 Shipset x China
Life Raft
2 x China
Electrics
Service Air Compressor: 1 x Taizhou Haihao, China - 15Nm³/h @ 7 bar, air-cooled
Air Pressure Bottles: 1 x Wuhan Zhongzhou, China - 300L with drainage & relief valves
F. O. Purifier: 1 x Zhejiang Huayi, China - ~600L centrifugal, automatic
Switchboard: 1 x Taixing Haichuan, China
Transformer: 2 x Yangzhou Enze, China
Lighting: 1 Shipset x Haixing, China
Wiper & CWS: 1 Shipset x Nantong Fangzhou, China
Electrical Cable: 1 Shipset x Jiangyang, China
Air Pressure Bottles: 1 x Wuhan Zhongzhou, China - 300L with drainage & relief valves
F. O. Purifier: 1 x Zhejiang Huayi, China - ~600L centrifugal, automatic
Switchboard: 1 x Taixing Haichuan, China
Transformer: 2 x Yangzhou Enze, China
Lighting: 1 Shipset x Haixing, China
Wiper & CWS: 1 Shipset x Nantong Fangzhou, China
Electrical Cable: 1 Shipset x Jiangyang, China
Electronics / Navigation
1 Shipset x JRC, Japan
Internal Communication: 1 Shipset x Jiaxing Kexun, China
MGPS: 1 x KC LTD, Korea
Internal Communication: 1 Shipset x Jiaxing Kexun, China
MGPS: 1 x KC LTD, Korea
Deck Gear
Steering Gear: 1 Shipset x Xinghua Kaiyuan, China - Electro-hydraulic, 50KNM, ±35° rudder angle
Remarks
Container capacity: 79 TEUs
Dwt: 1900 Ton
Length PP : 60.80m
Dead Weight : 1900mt
Depth : 4.50m
Design Draft : 2.80m
Scantling Draft: 3.50m
NOTE:
1. This list defines the subcontractors of major plants, machinery, equipmentandmaterials.
2. Where two or more makers are described for a single item, the Builder has the right to select the maker who offers the lowest price. If the Buyer prefers a maker who offers a higher price, the Buyer shall either push the maker to a lower price or bear the costs of the price difference. However, equipment must always meet the specification requirement.
3. Upon receipt of the information from the Builder about the name of the maker, the type of the equipment and the price adjustment calculation, the Owner should reply within seven (7) days. If not, the Builder shall consider that the Owner agrees with the Builder's selection automatically.
4. Other plants, machinery, equipment and material which are not mentioned in this list shall be supplied by the subcontractors selected by the Builder. However, equipment must meet specification's requirement.
5. If Builder or Owner like after signing of contract add or delete some maker, that could be done under mutual agreement of both parties
6.** mark: license in China.
Dwt: 1900 Ton
Length PP : 60.80m
Dead Weight : 1900mt
Depth : 4.50m
Design Draft : 2.80m
Scantling Draft: 3.50m
NOTE:
1. This list defines the subcontractors of major plants, machinery, equipmentandmaterials.
2. Where two or more makers are described for a single item, the Builder has the right to select the maker who offers the lowest price. If the Buyer prefers a maker who offers a higher price, the Buyer shall either push the maker to a lower price or bear the costs of the price difference. However, equipment must always meet the specification requirement.
3. Upon receipt of the information from the Builder about the name of the maker, the type of the equipment and the price adjustment calculation, the Owner should reply within seven (7) days. If not, the Builder shall consider that the Owner agrees with the Builder's selection automatically.
4. Other plants, machinery, equipment and material which are not mentioned in this list shall be supplied by the subcontractors selected by the Builder. However, equipment must meet specification's requirement.
5. If Builder or Owner like after signing of contract add or delete some maker, that could be done under mutual agreement of both parties
6.** mark: license in China.
