NEW 8.6m Landing Craft with Enclosed Wheelhouse
Length
28' 3" - 8.60m
Vessel Location
Italy
Model Year
2018
Hull Material
Aluminium
LAVAMPOSTO LC 860 is a tough, aluminum workboat suitable for a variety of demanding applications. Specifically designed to perform well even in difficult conditions, this boat offers huge deck space and loading capability but at the same time can be easily trailered. Every LAVAMPOSTO LC 860 is custom built and fully outfitted with all the necessary features and specifications that are exactly right for the duties it will be expected to perform.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Vessel Name
Built to Order
Boat Reference
2134
Model Year
2018
Length
28' 3" - 8.60m
Beam
2.55m (8ft 4in)m
Draft
0.55m (1ft 9in)m
Displacement
Tonnes
Vessel Location
Italy
Region
Europe
Use
Commercial
Hull Material
Aluminium
Max Speed
+27 knots
Fuel
300 lt.
Safety Gear
1 x electrical emergency pump in bilge, manual start.
1 x electrical emergency pump in engine room, manual start.
1 x electrical emergency pump in engine room, manual start.
Bilge Pumps
1 x manual bilge pump.
Fire Protection
1 x fire extinguisher at helmsman station.
Electrics
All electrical wiring in marine cable.
Shore power with control lamp, marked fuses, earth connection and shore cable.
Isolation transformer with earth plate for protection of galvanic corrosion.
24-volt electrical system.
Main switches with separate battery systems for start, navigation and consumption.
Battery charger with indicator.
1 x searchlight on cabin roof, manual operated.
Navigational lights.
1 x floodlight on the working aft deck
Shore power with control lamp, marked fuses, earth connection and shore cable.
Isolation transformer with earth plate for protection of galvanic corrosion.
24-volt electrical system.
Main switches with separate battery systems for start, navigation and consumption.
Battery charger with indicator.
1 x searchlight on cabin roof, manual operated.
Navigational lights.
1 x floodlight on the working aft deck
Electronics / Navigation
Electronics per Owner's requirements
Electric engine controls. Complete engine instruments with RPM, temperature, oil pressure and voltmeter for start batteries supplied by engine manufacturer.
Fuel gauge.
Control panel for all lighting and other electrical equipment.
1 x magnetic compass.
Electric engine controls. Complete engine instruments with RPM, temperature, oil pressure and voltmeter for start batteries supplied by engine manufacturer.
Fuel gauge.
Control panel for all lighting and other electrical equipment.
1 x magnetic compass.
Survey Details
Class: can be built to RINA Class or with CE Certification
Remarks
CHARACTERISTICS:
Height above waterline (cabin): 2.27m
Displacement Light weight: 2.550 kg
Displacement Full load: 3.850 kg
Maximum Load: 1300 kg
OPTIONS :
-Inboard diesel engine with sterndrive
-Outboard gas engine (single or double)
-Pilothouse or center console
-Side doors
-Dive ladders
-Towing post
-Push knees
-Lifting davit
-Lifting eyes
HULL, DECK AND SUPERSTRUCTURE:
Construction is in marine grade, fully welded, aluminium alloy of 5 and 6 MM. Thickness. An optional beaching plate gives 12 MM. At the contact with the beach.
DECK:
Watertight self-bailing decks are made of 5 MM. Aluminum plates. These are welded to transverse frames and bulkheads (spaced 800 MM. ) and longitudinals (spaced 280 MM. ). This structure is extremely strong and suitable for heavy work situations.
DECK LAYOUT:
The boat is offered in either pilothouse or central console configurations.
Dimensions and features of the pilothouse or the central console are per Owner's requirements.
The pilothouse is accessed through a sliding door and can be equipped with (optional) air-conditioning / heating.
Benches for up to 10 passengers can be positioned on the forward deck.
BOW DOOR:
1.35 mt. Wide and of heavy duty construction. Operated by manual or electric winch (optional hydraulic).
FENDER:
A variety of fendering options are available to address any operational requirement. They can be in heavy duty rubber, aluminum or a combination of both.
Height above waterline (cabin): 2.27m
Displacement Light weight: 2.550 kg
Displacement Full load: 3.850 kg
Maximum Load: 1300 kg
OPTIONS :
-Inboard diesel engine with sterndrive
-Outboard gas engine (single or double)
-Pilothouse or center console
-Side doors
-Dive ladders
-Towing post
-Push knees
-Lifting davit
-Lifting eyes
HULL, DECK AND SUPERSTRUCTURE:
Construction is in marine grade, fully welded, aluminium alloy of 5 and 6 MM. Thickness. An optional beaching plate gives 12 MM. At the contact with the beach.
DECK:
Watertight self-bailing decks are made of 5 MM. Aluminum plates. These are welded to transverse frames and bulkheads (spaced 800 MM. ) and longitudinals (spaced 280 MM. ). This structure is extremely strong and suitable for heavy work situations.
DECK LAYOUT:
The boat is offered in either pilothouse or central console configurations.
Dimensions and features of the pilothouse or the central console are per Owner's requirements.
The pilothouse is accessed through a sliding door and can be equipped with (optional) air-conditioning / heating.
Benches for up to 10 passengers can be positioned on the forward deck.
BOW DOOR:
1.35 mt. Wide and of heavy duty construction. Operated by manual or electric winch (optional hydraulic).
FENDER:
A variety of fendering options are available to address any operational requirement. They can be in heavy duty rubber, aluminum or a combination of both.
