NEW NEW BUILD - 10m Landing Craft with raised helm sta
Length
32' 8" - 9.96m
Model Year
2019
Hull Material
Aluminium
Of compact dimensions and easily transportable this is a landing craft that can offer the maximum of deck space, great cargo capacity and a protected wheelhouse. Designed for serious work in demanding conditions, the boat is built in aluminum alloys (RINa certified) of heavy scantlings. Class /Survey: RINA, CE Category: B / C. The raised wheelhouse is slightly moved offset to one side and offers good protection and excellent visibility to pilot and co-worker. At deck level there is also room for a small but useful toilet.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Boat Reference
1406
Model Year
2019
Length
32' 8" - 9.96m
Beam
3m (9ft 10in)
Draft
0.76m (2ft 5in)
Displacement
5.8 tons Tonnes
Region
Europe
Use
Charter, Commercial
Hull Material
Aluminium
Engine
1 x inboard diesel engine with sterndrive
2 x inboard diesel engines with sterndrives
1 x gas outboard installed on a bracket
2 x gas outboards installed on a bracket
Max Speed
+22 knots
Cruise Speed
18 knots with full load
Fuel
400 l (standard, can be customized to requirements)
Safety Gear
1 x electrical emergency pump in bilge, manual start.
1 x electrical emergency pump in engine room, manual start.
FENDER:
There are two hull guards of 4 mm. Aluminum placed at convenient height of the sides.
A 50 x 50 mm D profile. Hard rubber fender and is bolted to the top hull guard.
1 x electrical emergency pump in engine room, manual start.
FENDER:
There are two hull guards of 4 mm. Aluminum placed at convenient height of the sides.
A 50 x 50 mm D profile. Hard rubber fender and is bolted to the top hull guard.
Bilge Pumps
1 x manual bilge pump
Fire Protection
1 x fire extinguisher at helmsman station.
Electronics / Navigation
ELECTRICAL SYSTEM & LIGHTING:
All electrical wiring in marine cable.
Shore power with control lamp, marked fuses, earth connection and 20 m shore cable.
Isolation transformer with earth plate for protection of galvanic corrosion.
24-volt electrical system.
Main switches with separate battery systems for start, navigation and consumption.
Battery charger with indicator.
220 V-outlets in cabin.
1 x searchlight on cabin roof, manual operated.
Navigational lights.
1 x floodlight on the working aft deck
All electrical wiring in marine cable.
Shore power with control lamp, marked fuses, earth connection and 20 m shore cable.
Isolation transformer with earth plate for protection of galvanic corrosion.
24-volt electrical system.
Main switches with separate battery systems for start, navigation and consumption.
Battery charger with indicator.
220 V-outlets in cabin.
1 x searchlight on cabin roof, manual operated.
Navigational lights.
1 x floodlight on the working aft deck
Remarks
Of compact dimensions and easily transportable this is a landing craft that can offer the maximum of deck space, great cargo capacity and a protected wheelhouse.
Designed for serious work in demanding conditions, the boat is built in aluminum alloys (RINa certified) of heavy scantlings.
Class /Survey: RINA, CE Category: B / C.
The raised wheelhouse is slightly moved offset to one side and offers good protection and excellent visibility to pilot and co-worker. At deck level there is also room for a small but useful toilet.
DIMENSIONS:
Displacement Light weight: 3,500 kg
Displacement Full load: 5,800 kg
Maximum Load: 2300 kg
HULL, DECK AND SUPERSTRUCTURE:
The boat is built of heavy scantlings aluminum alloy plates and extrusions, RINa certified for marine use. Bottom plates are 6 mm. Thick, sides 5 mm. Internal structure are 6 and 10 mm. Thick.
Deck is 5 mm. And wheelhouse 4 mm..
DECK:
Decks are fully self bailing.
Large working area.
Easily removable deck sections.
Access hatch to engine room.
Wide bow door, with hydraulic or manual opening system.
1 x hydraulic crane (optional)
1 x horizontal hydraulic winch in the aft platform.
1 x towing bollard.
6 x mooring bites.
Storage for mooring equipment.
Watertight storage in several compartments.
Watertight storage cabinet for rainwear.
Large storage areas for up to 6 x 50 Lt air bottles
FUEL CAPACITY:
1 (optional 2) x 400 litre fuel tank with hatch and filling protection.
All fuel systems are pressure tested.
Designed for serious work in demanding conditions, the boat is built in aluminum alloys (RINa certified) of heavy scantlings.
Class /Survey: RINA, CE Category: B / C.
The raised wheelhouse is slightly moved offset to one side and offers good protection and excellent visibility to pilot and co-worker. At deck level there is also room for a small but useful toilet.
DIMENSIONS:
Displacement Light weight: 3,500 kg
Displacement Full load: 5,800 kg
Maximum Load: 2300 kg
HULL, DECK AND SUPERSTRUCTURE:
The boat is built of heavy scantlings aluminum alloy plates and extrusions, RINa certified for marine use. Bottom plates are 6 mm. Thick, sides 5 mm. Internal structure are 6 and 10 mm. Thick.
Deck is 5 mm. And wheelhouse 4 mm..
DECK:
Decks are fully self bailing.
Large working area.
Easily removable deck sections.
Access hatch to engine room.
Wide bow door, with hydraulic or manual opening system.
1 x hydraulic crane (optional)
1 x horizontal hydraulic winch in the aft platform.
1 x towing bollard.
6 x mooring bites.
Storage for mooring equipment.
Watertight storage in several compartments.
Watertight storage cabinet for rainwear.
Large storage areas for up to 6 x 50 Lt air bottles
FUEL CAPACITY:
1 (optional 2) x 400 litre fuel tank with hatch and filling protection.
All fuel systems are pressure tested.
