NEW Safehaven Interceptor 60 Pilot Boat


Length
62' 4" - 19.00m
Use
Commercial
Vessel Location
Ex factory, Ireland
Model Year
2017
Hull Material
Fibreglass/GRP

The Interceptor 60 / 18.5m pilot vessel has a L. O. A. Of 19.5m and offers Ports and operators the option of pilot vessel with the highest levels of endurance and sea keeping and is suitable for operations where transfers occur far offshore, and where very rough sea conditions may prevail, or where the capacity to carry up to 12 pilots is required and provide for a long endurance capability allowing full live aboard facilities.

SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.


Vessel Name
Built to Order
Boat Reference
4036
Model Year
2017
Length
62' 4" - 19.00m
Beam
5m (16ft 4in)m
Draft
1.5m (4ft 11in)m
Displacement
Tonnes
Vessel Location
Ex Factory, Ireland
Region
Europe
Hull Material
Fibreglass/GRP
Engine
Power Output: 873hp Gearboxes: Twin Disc 5135 ENGINEERING Main Engines The vessel is fitted with twin Caterpillar C18 873hp engines and TWIN DISC MG5135 gear boxes 1.75:1 ratio. Each engine is fitted with 6 x H/D adjustable flexible mountings. (four for engine and two extra for gearbox) The engines are mounted on 125 mm solid cored engine beds bolted through taped glassed in 15mm steel with 16mm bolts. The machinery is installed in accordance with the manufacturer's recommendations and installation instructions and commissioned by the appointed agent / engineer and tested to provide conformity with the manufacturer's recommendations. Care and attention is paid to providing durable machinery installation with adequate support and neatness on all piping and cable runs. Special attention is paid to provide ease of ongoing maintenance and ensuring all service items are readily accessible. All piping and connections to the engine and throughout the overall installation are to be of an approved type. Speed Maximum 28kts (half loaded) The vessel shall provide for a maximum speed of 28kts (50% loaded) with Caterpillar C18 engines (Medium duty rating D) 873hp, At 100% of maximum power (873hp) the maximum speed will be allowable for 1 out of 12 hrs. Cruise 23-24kts (Continuous operation) The vessel shall provide for a maximum operational speed (cruise) of 23-24kts with Caterpillar C18 873hp engines (Medium duty rating D) The cruise speed is with the engineers delivering 715hp (80% of max power), their maximum continuous rating (MCR). The vessel operates equally well at transition speeds from 16-28kts Engine Controls & Instrumentation Single lever electronic shift controls are fitted at the main helm positioned, ergonomically positioned for ease of operation or electronic controls. The engine panel is fitted with the standard manufactures instrumentation comprising a 7" LCD colour display (this replaces
Max Speed
28 knots
Cruise Speed
25 knots
Genset
10kw
Fuel
2500L
Accommodation
Pilot Seating Cap. : 12 Pilots, 1-2 Crew

INTERIOR
Accommodation
Fore Peak
The fore peak extends aft of the bow and is a void space provided with a sole and capable of being used as a storage area. There is full access to all fittings and the area is flow coated. The area is accessed from the forecabin via a watertight door in the b/head. And from the deck via ladder and a Hercules aluminium deck hatch. The anchor, chain and warp is stored in a recessed anchor locker accessed from the deck.

Forward Accommodation
A large, spacious accommodation area extends between the fore peak and the f/wd engine room b/head and offer full live aboard facilities and space for her crew should this be a requirement. This are provides a full galley with a sink and pressurised water, a 240 v mains outlet for a microwave and a kettle are fitted. Lockers provide storage space. A spacious dinette area for 6 persons is provided opposite with a table between. To port are two bunk berths.

Heads Compartment
A separate heads compartment on the st/bd side is accessed from the forward accommodation and is fitted with a electric Jabsco sea toilet, with overboard discharge. A S/S sink with fresh water tap.
A basic storage area is provided here. The compartment is flow coated white with access to all hull fittings (fender bolts)

Wheelhouse
The wheelhouse is divided into two separate areas, crew compartment and pilot / passenger compartment.

Crew Compartment
The crew compartment f/wd contains a central helm position which facilitates ease of coming alongside on either port or starboard. A GRP helm console fitted with a horizontal steering wheel (bus / lifeboat style) with a recessed foot rest allowing comfortable posture when steering. The engine controls fall easily to hand. All engine instrumentation and navigational equipment is easily viewed and easily operated. The wheel house windows are aft slopping to minimise pressure loadings on the glass are when impacted from large breaking seas. The helm position is fitted with a CAB 500 Series hydraulic damped and sprung helm set on a pedestal. Adjustable for height and fore and aft adjustment. A navigators position is positioned to st/bd and a crew position is positioned to port, both with suspension seating.

Pilot / VIP passenger compartment
A partition with large glass panels and door divides the compartments.
The Pilot / passenger cabin is fitted with 11 similar CAB 500 Series pilot seats (depending on requirements for the amount of pilots the port needs to carry) on GRP Pedestals with footrests. There is in addition (depending on seating requirements the option of a U shaped settee and table at the aft of the cabin and work top opposite with storage lockers underneath. The cabin sole is of black studded rubber as standard with the option of Teak and holy sole if a more luxurious environment is required.
Electronics / Navigation
Steering System
The vessel is fitted with a POWER hydraulic steering system consisting of a HYPRO MARINE engine driven 170cc power pump, tiller cylinder steering ram and helm pump, providing the craft with a hard over to hard over of 3.5 wheel turns without being overly heavy in steering effort. Fitted with a bypass valve to allow operation via the emergency steering tiller arm. The system uses hydraulic hose to connect the steering system throughout the installation.
An emergency steering tiller is supplied and stowed in the aft compartment.
Survey Details
Lloyds
Remarks
L. O. A: 19m
Length Moulded: 18m
Beam: 5m
Beam Moulded: 4.6m
Draft: 1.5m
Displacement Lightship: 26,000kg

DESIGN
General Description
The Interceptor 60 is of GRP construction. Its hull design is of a Deep V, twin chine, semi displacement design providing excellent sea keeping especially in big Atlantic or Ocean waves, or where tidal influences introduce dangerous breaking seas. The design is capable of operating safely in all weather conditions up to and including Storm force 10-11 and wave heights up to 8m+. The vessel displays safe, predictable 'alongside ship' handling characteristics and can be specified as Self-Righting, able to recover safely after capsize by a large breaking wave.

Design / Sea Keeping
The Interceptor has a wide beam combined with moderately deep V aft sections this provides the necessary high levels of directional stability needed to prevent any yaw and roll that can induce broaching, when surfing on the face of large waves. This beam, coupled with a very low centre of gravity are the designs key factors in being able to run safely, in big quartering following seas. Quick light steering with minimum turns lock to lock, and large rudders give instant correction to the helm inputs. The bow design is full above the waterline with plenty of flare, this gives sufficient buoyancy to prevent shipping green water. Running into big head seas the design is excellent. Her deep V hull sections, 22 degrees amidships, and a fine 52 degree waterline entry at the bow means she is very soft riding, with low vertical accelerations for crew comfort. She has a high bow with plenty of freeboard forward and amidships. The superstructure is positioned well aft for crew comfort. The designs 'twin chines' make her a very dry boat, especially so at boarding speeds, and her bow flare contributes to this. The hull design is also excellent in a short 1-2m chop, her fine forward sections effectively cut through smaller waves providing a smooth ride.

The Self-Righting Capabilities of the Interceptor Pilot Boat'
From the outset, an important part of the design criteria for the interceptor 60, was that the vessel to be inherently self-righting. This is achieved as a result of the superstructure designs size and buoyancy, preventing the vessel from staying in an inverted position after capsize by a breaking sea. The superstructure is of a size large enough, with enough internal volume to automatically right the vessel.
Obviously there are a number of other factors affecting the self-righting capabilities of a vessel, and the Interceptor 60 pilot boat incorporates a number of design features to achieve self-righting.
