NEW Integrity 520 SX Plus


Price
AU $1,825,773 Available to order
Finance
Pre-Purchase Inspection
Currency
Length
54' 6" - 16.60m
Vessel Location
Hollywell QLD
Model Year
New
Hull Material
Fibreglass/GRP

Designed for the owner that would like the option of faster performance when needed, combined with low cost comfortable cruising the 520 SX Plus boasts huge interior volume, open plan layout perfect for entertaining, aft galley, two stateroom, two bathroom, full beam midship master the 520SX has it all!

This lastest innovation to our range offers semi-displacement cruising, capable of max speeds of 22 knots and cruising around 16 knots. But remains true to the timeless lines have provided inspiration for the new Integrity SX range. Contemporary design elements have been incorporated to ensure our new range has a striking on water appearance.

Integrity Motor Yachts have travelled untold thousands of sea miles making the seakeeping abilities of our vessels without question. The class leading beam ensures stability in all conditions. The displacement hull, greater beam, full length keel and additional weight ensures stability while underway in the most trying conditions or when at rest.

Our hulls are laid up to survey standard along with vinyl ester tie layers for strength, durability and osmosis protection. FGI Gelcoat is used on the exterior of the hulls specifically formulated and applied to suit Australian conditions.

Vessel hull slap is an annoying issue that anyone who has tried to get a restful sleep on a "loud" boat at anchor will recognise. The design of the hull featuring no planing strakes means very minimal or no slap at rest.

Bow and stern thrusters as standard offer finger-tip control ensuring simple and easy berthing in all conditions. Side and stern access from the swim platform means boarding is safe and simple, no leaps of faith required.

There is easy access to all areas of the boat fore and aft, with wide side deck walk arounds and high handrails ensuring safety for passengers at anchor or underway.

The wide swim platform is perfect for on water recreation. Featuring a sturdy boarding ladder and a retractable hot and cold freshwater shower. Stainless stern rails can be added to accommodate a BBQ, bait preparation boards, tenders and rod holders.

The beamy cockpit layout features full wrap around seating and a drop-down teak table creating additional sea berth accommodation or a day bed. There is ample under-seat storage and a self-draining ice box that can be converted to extra refrigeration if required.

Ensuring an easy flow throughout the vessel main deck the cockpit connects via a trademark wide hopper window and door to a spacious open plan saloon and aft galley servery. A layout providing the opportunity for seamless indoor/outdoor entertaining.

An Onan diesel powered generator and inverter are standard allowing for all of your 240V electricity needs. Reverse cycle air-conditioning is available as an option ensuring comfortable cruising in any climate.

If you have considered cruising makes such as Clipper Alaska Greenline Newport Back Cove Grand Banks or the Swift Trawler, the Integrity Motor Yachts range definitely needs to be considered.

Call Spectrum Marine now for more information and to arrange an inspection.

We have used our best endeavours to ensure that the information contained herein is true and accurate, but accept no responsibility and disclaim all liability in respect of any errors. Any prospective purchaser is encouraged to verify any specifics on specification or condition of a used vessel by way of third party inspector.


Price
AU $1,825,773 Available to order
Vessel Name
New Integrity
Boat Reference
NewINT520SXPlus
Model Year
New
Length
54' 6" - 16.60m
Beam
5.26m
Draft
1.4m
Displacement
Tonnes
Vessel Location
Hollywell Qld
Region
Queensland
Use
Family, Leisure, Cruising
HIN
NewInteg520SXplus
Registration
New
Rego Expiry
31/12/2024
Designer
Integrity/Bill Upfold
Builder
Integrity Motor Yachts
Hull Material
Fibreglass/GRP
Decks Material
GRP
Engine
Single Volvo Penta D13 900hp with ZF Gearbox and twin 8hp Thrusters
Engine Make
Volvo Penta
Number Engines
1
Horsepower
900
Fuel Type
Diesel
Max Speed
22
Cruise Speed
16
Propulsion
Shaft Drive
Thrusters
Bow and Stern Thrusters 24V 8HP each
Genset
11kw
Fuel
2500
Water
1000
Accommodation
Full Beam Midship Master Cabin, with private entrance door, Ensuite with seperate shower, large porthole windows, 2 opening. Forward VIP Stateroom with private entrance door, Ensuite with seperate shower, opening porthole windows
Cabins
2
Berths
4 in 2 cabins
Shower
2
Toilet
2
Entertainment
Option to owners specification
Air-Con
20,000 BTU to Saloon with 12,000 BTU for downstairs
Galley
Induction cooktop (2 x burner)
Microwave - powered off inverter
2 under bench refrigerators in galley
Galley benchtop solid surface, stainless steel sinks
with single mixer with covers
Sink recesses in benchtop with covers
Galley storage cabinets and soft close drawers
Overhead storage cabinets above galley
LED lighting overhead 24v
Refrigeration
2 under bench refrigerators in galley
Freezer
Option to owners specification
Stove
Induction cooktop (2 x burner), Microwave - powered off inverter
Water-Maker
Option
Hot Water
Yes, 240 volt and off engine
Ground Tackle
Anchor 27kgs (60lbs) & 80mtrs of chain. Winch 24V with foot switches
Safety Gear
Various
Bilge Pumps
Bilge pumps auto with manual override and high water alarms x 3, Manual bilge pump system
Life Raft
Option
Epirb
Option
Life Jackets
Yes
Flares
Yes
Electrics
Generator 11kw
Battery charger/inverter 24v 3kva
House Batteries- 400Ahr 24VDC, maintenance free
Engine Batteries -110Ahr 24VCD, Genset Battery 110Ahr 24VDC
All batteries fitted in GRP battery boxes
Battery paralleling system for emergency engine start
All AC power outlets RCD protected
Electronics / Navigation
Option to owners specification
Deck Gear
Anchor locker accessed by 2 hatches on deck
Anchor safety strap
Bow rail welded stainless (316) flag staff at bow
Bow roller stainless self loading
Cleats stainless steel x 8,(Bow x 2, Spring x 2, and Stern x 2)
Docking lines and fenders x 4
Escape deck hatch from forward cabin stainless steel
Exterior courtesy deck lights
Fuel fillers on side decks
Fwd windscreen in safety glass bonded to FRP frames
Rub Rail with stainless steel insert
Non slip on fwd deck house, side & foredecks & saloon roof
Sliding Side door to FRP deck house frame
Stainless steel swim ladder
Wash down tap (sea water & fresh) in anchor locker
