NEW Majesty 120

Length Overall: 37.076m (121ft 8in)
Length Water Line: 31.382m (102ft 9in)
Draft: 2.1m 6ft 9in)
Beam: 8.089m (26ft 6in)
Air Draft: 13.175m (43ft 2in)
Yacht Type: Motor Yacht
Gross Tonnage: 295 GT
Classification: RINA Pleasure
Lube Oil Capacity (Clean + Dirty): 63+63 US Gal; 238+239 Litres
18 knots*
Range @ Cruising Speed: 1153 NM*

MAJESTY 120 OPTIONS
The options selected from the below list and any additional requirement shall be considered as a variation and upon confirmation shall become a part of Work Order
1. RINA commercial classification for chartering
2. Compliance with Maritime and Coast Guard Agency (MCA) Large Yacht Code LY3
3. Compliance for Unrestricted navigation
4. Yacht name
5. Aft search light
6. Awning on sundeck aft
7. Awning on upper deck forward
8. Awning on upper deck aft
9. Satellite communication system
10. Electrohydraulic crane with safe working load of 770 kg on foredeck
11. Shore power converter
12. Isolation Transformer
13. Electrohydraulic transformer, 1000 kg lifting capacity with Williams DieselJet 415
14. Electrohydraulic transformer, 1300 kg lifting capacity with Williams DieselJet 505
15. AFT crane with 1000kg lifting capacity
16. Cradle for tender
17. Multifunctional Ladder
18. Electrohydraulic Passarella
19. Electric stern thruster
20. Side mount ladder
21. Removable 316L Stainless Steel Staple Rails on Swim Platform

GENERAL INFORMATION
The design and construction shall be strictly in accordance with the following specifications that describe the standard Yacht version
Design, exterior styling, and interior design shall be performed by the Gulf Craft Inc as per the attached General Arrangement
Any additional design requirements or any changes in design or technical to this standard specification shall be considered as a variation and shall become part of Work Order.

HULL AND SUPERSTRUCTURE
Reinforcements: Fiber Glass
Resin: Vinylester resin and Polyester resin
Core materials: SAN Foam-typical for marine applications, Balsa wood

Construction Process
Hand-layup lamination process is employed. Hull and superstructure are laminated into female molds.
During construction process yacht is kept in clean conditions. All finished work is thoroughly protected. Particular attention is given to the covering of materials that could absorb impacts from tools, materials, and workers
Hazards associated with the handling of composite materials is minimized

Exterior Finishing
Hull and superstructure are painted in White and Black. The painting work is carried under cover in controlled environment conditions (temperature, humidity, and dust). Manufacturer's recommended procedures are adopted for surface preparation, mixing and reduction, and maintenance of coatings.


SUPERSTRUCTURE
Sundeck
316L Stainless Steel Railings
L-Shaped Upholstered Sofa With Coffee Table
Wet Bar With Sink, BBQ Grill, And Following Appliances
Under Counter Fridge
Ice Maker
Four Bar Stools With 316L Stainless Steel Bases
Jacuzzi With Sunbed
Three Sun Loungers With Side Tables
Warm White Exterior Lights
Teak Decking
Self-Draining

Foredeck
316L Stainless Steel Railings
Flag Post
Four 316L Stainless Steel Deck Cleats
Two 316L Fairleads with Rollers
Two Freeing Ports
Watertight Hatch Anchor Chain Compartments
Teak Decking
Self-Draining

Upper Deck
316L Stainless Steel Railings
Rail Track For Cleaning
Sunbed With Safety Railing
Upholstered Sofa with Two Teak Dining Tables
Pantograph Doors To Wheelhouse On Port And Starboard
Stairway To Sundeck On Aft Port Side
Sliding Patio Door
Service Counter On Starboard
One 3-Seater Sofa + End Table
Two 1-Seater + Coffee Table
Teak Decking
Self-Draining

Main Deck
316L Stainless Steel Railings
316L Stainless Steel Deck Cleats on Aft
Two Freeing Ports
Weathertight Doors To Pantry And Lobby
Sliding Patio Door
Stairway To Upper Deck On Port
Weathertight Door And Stairway To Crew Mess And Pantry On Port Gunnel
Countertop With Washing Sink On Starboard
Upholstered Sofa With Teak Dining Table And Four Chairs
316L Stainless Steel Transom Doors
Teak Decking
Self-Draining

Swim Platform
Electrohydraulic Stern Door
Two 316L Stainless Steel Pop-Up Cleats
Swim Ladder
Teak Decking

Accommodation Layout
The arrangement and accommodation layout shall be according to the General Arrangement Plan and Profile
There are six guest cabins including the owner's cabin, two double guest cabins, two twin guest cabin, and a VIP cabin. Each guest cabin has an en-suite bathroom
There are three crew cabins with en-suite bathrooms in the aft, and a captain's cabin with en-suite bathroom on upper deck
Also, day heads on Main deck and Upper deck

Interceptors
Four electrically operated interceptors will be fitted on the transom. Interceptors system will be interconnected with the stabilizers for combined operation while sailing. Int
