35.8m Traditional Motor Vessel


Price
Euro €1,350,000 Finance
Currency
Length
117' 5" - 35.80m
Use
Commercial
Vessel Location
Denmark Insurance
Launch Year
1941
Hull Material
Steel Riveted

M/S NAVIGATOR - Maritime traditions and Nordic luxury. M/S NAVIGATOR is a riveted steel ship built in 1941. This unique and traditional vessel has been fully refitted paying full attention to Danish quality and design traditions. Preserving tradition - celebrating Nordic culture and design The history of M/S NAVIGATOR relates to Danish maritime traditions and the Port of Copenhagen. The ship was originally built as a cable ship in 1941 per the highest standards of the industrial area. Subsequently, in 1962 it was rebuilt as a training vessel for Danish merchant marine officers. During the period 2005 - 2011 M/S NAVIGATOR was renovated while paying respect to the historical value of this unique sample of the official Danish fleet. The ship went through an exhaustive overhaul, cosmetically but also in its functionality. It was decided to preserve the original exterior appearance as well as the interior of the crew quarters. Likewise, the machine room was refitted per its original design while adding elements required by today's standards. The remainder of the ship's interior has on the contrary been fully updated per Danish quality and interior design traditions. Gentle environmental footprints M/S NAVIGATOR pays respect to the environment. Remarkably low fuel consumption marks the difference between traditional and modern naval dimensioning. On board, it is the policy of the crew to observe minimum waste and consumption. Accommodation: (10) - Suite (2 persons) with king size bed, private entrance hall and large bath room with shower and bathtub (12) - State room (2 persons) with double beds and en-suite bathrooms (13) - State room (2 persons) with double beds and en-suite bathrooms (6) - State room (1 person) with a large bathroom. No of guests at daytime: 12, No of guests sleeping: 7, No of crew - sailing: Min. 6.


Price
Euro €1,350,000    Finance    Insurance
Boat Reference
1367
Launch Year
1941
Length
117' 5" - 35.80m
Beam
7.5m (24ft 8in)
Draft
2.6 (8ft 5in)
Displacement
293 tons
Vessel Location
Denmark
Region
Europe
Hull Material
Steel Riveted
Engine
B&W Alpha Diesel type 404 F / 206 kW / 375 rpm
Fuel Consumption
40 liters/hour
Max Speed
9 knots (375 rpm)
Cruise Speed
7.5 knots (330 rpm)
Fuel
16,000 liters
Water
8000 liters
Accommodation
(10) - Suite (2 persons) with king size bed, private entrance hall and large bath room
with shower and bathtub
(12) - State room (2 persons) with double beds and en-suite bathrooms
(13) - State room (2 persons) with double beds and en-suite bathrooms
(6) - State room (1 person) with a large bathroom

No of guests at daytime: 12
No of guests sleeping: 7
No of crew - sailing: Min. 6
Shower
Large bath room with shower and bathtub
Entertainment
Bang & Olufsen
B&O link system
B&O Beomaster 5000 digital music systemo B&O speakers
3 B&O Televisions
Wi-Fi
Net 1 connections (covering part of the charter area)
Galley
Miele dishwasher
Reneka espresso machine and grinder
2 sinks with food waste disposers
Miele washing machine and dryer
Refrigeration
Additional Siemens refrigerator (galley) and Siemens freezer (stores room).
Gaggenau refrigerator
Freezer
Freezer & ice maker.
Stove
Olis professional gas oven and stove. Miele microwave / grill / hot air oven.
Ground Tackle
2 * anchors
Anchor winch - Thomas B. Thrige (220 V DC)
Capstan winch - Thomas B. Thrige (220 V DC)
MOB crane (850 kg) - ACTA
Crane on fore deck (100 kg)
2 Wiska search lights
Safety Gear
Zodiac RIB / MOB certificate / 5.5 meters (18 feet) / 115 hp - max 14 persons
FM 200 machine room fire extinguisher
ServoFighter C4 fire alarm system
Smoke indicators in all cabins/rooms
2 * Automatic fire doors
2 Wiska search lights
Bilge Pumps
2 independent bilge pump-systems
Life Raft
2 * Zodiac 20 EC life rafts for 20 people each
Epirb
YES
Life Jackets
20 Secumar auto-inflatable life-jackets + 2 life-jackets for children
Fire Protection
FM 200 machine room fire extinguisher, ServoFighter C4 fire alarm system Smoke 11 fire extinguishers
Electronics / Navigation
Depth sounder: Furuno LS-4100
Marine radar: Furuno FR-360 Mark II
Magnetic compass: NS150A
GPS: Furuno WAAS NAVIGATOR
Steering machine: Svendborg
Auto pilot: Simrad AP70
AIS: Jotron TR-8000
Remarks
Built: 1941/ Nakskov Skibsværft / Denmark / Building No. 103
Refit (1): 1961-1962/Sønderborg Skibsværft
Refit (2): 2005-2011/Århus Værft, Ring Andersens Værft et. Al.
Type: Motor vessel

Tonnage net: 41.5
Range: 2.400 nm

Flag: Danish
Class: Danish Maritime Authority
Charter area: Danish domestic waters, Southern Norway, Swedish coast and the Baltic Sea
Staterooms: 5

Technical equipment
Heating system: Air handler unit / electric floor heating
Air handler unit: LUBI, LVA-13 / 21.3 kW heating
Sanitary system: Grey water tank capacity: 6.000 liters
Black water capacity: 5.000 liters
Electrical system: IHC (computer) managed electrical system
Alarm and monitoring system: ViewCOM 6300 (Hastrup Automation/Phoenix Contact)
Diesel tanks
Engines
Bilge water
Water tanks (fresh and sanitary water)
Pumps
Air handler unit
Fire alarm

M/S NAVIGATOR - Maritime traditions and Nordic luxury
M/S NAVIGATOR is a riveted steel ship built in 1941. This unique and traditional vessel has been fully refitted paying full attention to Danish quality and design traditions.

Preserving tradition - celebrating Nordic culture and design
The history of M/S NAVIGATOR relates to Danish maritime traditions and the Port of Copenhagen. The ship was originally built as a cable ship in 1941 per the highest standards of the industrial area. Subsequently, in 1962 it was rebuilt as a training vessel for Danish merchant marine officers.
During the period 2005 - 2011 M/S NAVIGATOR was renovated while paying respect to the historical value of this unique sample of the official Danish fleet. The ship went through an exhaustive overhaul, cosmetically but also in its functionality. It was decided to preserve the original exterior appearance as well as the interior of the crew quarters. Likewise, the machine room was refitted per its original design while adding elements required by today's standards. The remainder of the ship's interior has on the contrary been fully updated per Danish quality and interior design traditions.

Gentle environmental footprints
M/S NAVIGATOR pays respect to the environment. Remarkably low fuel consumption marks the difference between traditional and modern naval dimensioning. On board, it is the policy of the crew to observe minimum waste and consumption.

General Arrangement
The central brass-plated hall (3) connects all three interior decks.

On the boat deck you find a large saloon (1) and the wheel house (2).

The main deck, aft of the hall (3) has a the dining/meeting room (4) with a table seating up to 12 guests followed by the galley (5). In front of the hall a single stateroom (6) with a big bathroom (7) and a guest toilet (8). Next to the stateroom the captain's cabin (9) is situated.

On tween deck you find a very large suite (10) with a private entrance hall and a large bathroom (11). Here you also find two double staterooms (12) + (13) - each with en suite bathrooms. Further the tween deck contains a crew cabin (14) and a laundry room (15).

Crew quarters (16) are situated on the main deck and the tween deck aft.

The floors are "floating" and the lining is fitted with rubber absorbers to minimize noise and vibrations. Most of the floors and the main staircase in the hall are covered with lava clinker from mount Edna/Sicily; all furniture is manufactured in teak. As a counter balance to the modern interior the original doors, door handles, fire alarm bells and internal communication system have been refitted.
