41m Surface Freezer Longliner
Length
133' 10" - 40.80m
Vessel Location
Spain
Launch Year
2017
Hull Material
Steel
Hull: Steel. Classification: Bureau Veritas. Total Fish Hold capacity: 200 tons. Average Fuel Consumption: 2,400 liters/day. Main Engine: ABC model 6DZC Serial Nº:14069. Accommodation: 22 Crew Members. Last Drydock: August 2024.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Boat Reference
5190
Launch Year
2017
Length
133' 10" - 40.80m
Beam
8.6m (28ft 2in)
Draft
3.65m 11ft 11in)
Vessel Location
Spain
Region
Europe
Use
In-shore Fishing, Off-shore Fishing
Hull Material
Steel
Engine
Propulsion System
Main Engine: ABC model 6DZC Serial Nº:14069
Power: 1.240 HP / 925 KW
Reduction Ger: Reinjest WAF1143, Ratio: 3,037/1
Propeller Shaft: 197 mm
Generator: Stamford, Power: 248 kW
Auxiliary Engines
3x Cummins QSM11-DM-HCM434F1, Power: 265 KW
Accommodation
22 Crew Members
Refrigeration
Refrigeration System
Refrigerant R-404-A. Cooling system: DIRECT EXPANSION.
Freezing Capacity: 7-8 tons/day
2x Freezing Tunnels
Refrigeration Compressors:
2x Bitzer OSN-7471K
1x Bitzer OSN-7441K
1x Bitzer 4FES-3Y
Refrigerant R-404-A. Cooling system: DIRECT EXPANSION.
Freezing Capacity: 7-8 tons/day
2x Freezing Tunnels
Refrigeration Compressors:
2x Bitzer OSN-7471K
1x Bitzer OSN-7441K
1x Bitzer 4FES-3Y
Electronics / Navigation
Electronic Equipment
Modern & Fully Equipped:
SOLAS Echo Sounder FURUNO FE-800
Non- SOLAS Echo Sounder FURUNO FCV-1150
NAVTEX FURUNO NX-700B
A. I. S. FURUNO FA-170
SOLAS Radar FURUNO FAR-2127
Non-SOLAS Radar FURUNO FAR-2127BB
SOLAS GPS FURUNO GP-170
3 x Non-SOLAS GPS 2 x FURUNO SC-50 and 1 x FURUNO GP-39
Modern & Fully Equipped:
SOLAS Echo Sounder FURUNO FE-800
Non- SOLAS Echo Sounder FURUNO FCV-1150
NAVTEX FURUNO NX-700B
A. I. S. FURUNO FA-170
SOLAS Radar FURUNO FAR-2127
Non-SOLAS Radar FURUNO FAR-2127BB
SOLAS GPS FURUNO GP-170
3 x Non-SOLAS GPS 2 x FURUNO SC-50 and 1 x FURUNO GP-39
Deck Gear
Fishing and Deck Machinery
2x Hydraulic Cranes Lifting Capacity: 1,20 Tm y 0,7650 Tm
1x Servo Motor Lifting Capacity: 5 Tm
1x Windlass
3x Bilge Pumps AZCUE, Power: 5,50 kW; Flow rate: 30 m³/h; Pressure:2,80 kg/cm2
1x Fuel Transfer Pump Power: 7,50 kW; Flow rate: 3 m³/h; Pressure: 3 kg/cm2
2x Fresh Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Sea Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Air Compressors Power 7,50 kW, Pressure: 30 kg/cm 2
2x Starting Air Bottles Pressure: 30 bar; Capacity: 125 l
1x Oil Separator DELTA, Capacity: 0,50 m³/h
2x Hydraulic Cranes Lifting Capacity: 1,20 Tm y 0,7650 Tm
1x Servo Motor Lifting Capacity: 5 Tm
1x Windlass
3x Bilge Pumps AZCUE, Power: 5,50 kW; Flow rate: 30 m³/h; Pressure:2,80 kg/cm2
1x Fuel Transfer Pump Power: 7,50 kW; Flow rate: 3 m³/h; Pressure: 3 kg/cm2
2x Fresh Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Sea Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Air Compressors Power 7,50 kW, Pressure: 30 kg/cm 2
2x Starting Air Bottles Pressure: 30 bar; Capacity: 125 l
1x Oil Separator DELTA, Capacity: 0,50 m³/h
Survey Details
Classification: Bureau Veritas
Last Drydock: August 2024
Last Drydock: August 2024
Remarks
Type of Vessel: Surface Freezer Longliner
Hull: Steel
Year of Construction: 2017
Capacities
Total Fish Hold capacity: 200 tons
(140 t in the hold + 50 t in the tween deck + 10 t in the freezing tunnels)
Fuel capacity (approx. ): 135.12 m³
Average Fuel Consumption: 2,400 liters/day
Oil capacity: 8.93 m³
Fresh Water capacity: 6,08 m³
Hull: Steel
Year of Construction: 2017
Capacities
Total Fish Hold capacity: 200 tons
(140 t in the hold + 50 t in the tween deck + 10 t in the freezing tunnels)
Fuel capacity (approx. ): 135.12 m³
Average Fuel Consumption: 2,400 liters/day
Oil capacity: 8.93 m³
Fresh Water capacity: 6,08 m³
