68m Landing Craft
Price
US $6,500,000
Currency
Length
223' 1" - 68.00m
Vessel Location
Malaysia
Launch Year
2024
Hull Material
Steel
Basic Function: Transporting Cargo. Classification: Class BV. Descriptive note: Specialized Designed to transport and deliver cargo. Free Running Speed: Est. 11 Knots. Main Engine: 2x Yanmar, 6EY17W 1138ps@1450rpm, heat exchanger cooled, electric start. Berths Total: 14 men.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
SeaBoats are International Ship Brokers & Yacht Brokers, marketing and selling a wide range of boats and ships, recreational and commercial, new and used, to broad global audiences. Our dedicated international teams of are strategically located around the world and utilize modern communication strategies and a vast network of industry associates.
Whether buying or selling, let the SeaBoats team work for you.
Price
US $6,500,000
Boat Reference
4876
Launch Year
2024
Length
223' 1" - 68.00m
Vessel Location
Malaysia
Region
Asia
Use
Commercial
Hull Material
Steel
Engine
PERFORMANCES
Free Running Speed: Est. 11 Knots
TANK CAPACITY
Fuel Oil: Approx. 340m3
Long Range FO: Approx. 1106m3
Fresh Water: Approx. 183m3
Ballast Water Approx. 561m3
PROPULSION SYSTEM
Main Engine: 2x Yanmar, 6EY17W 1138ps@1450rpm, heat exchanger cooled, electric start
Gear Box: 2x Reintjes, WAF563, Ratio 5.05:1
Rudder: 2x Mentrade (material), mild steel type
Steering Gear System: 1x Palamarine, Singapore or Equal, PEH3002-2P, Electro-hydraulic, 2 x 3.0T-Mile bar steering gear system at 35 steering angle with 1 unit dual pumps electro hpu, fitted in conjuction with an emergency hand hydraulic steering in the wheelhouse, Joystick type steering levers to be fitted on forward wheelhouse control console
Stern Tube Seal: 2x China, water lubricated
Stern Tube Bearing: 2x China, BTC Cuttles bearing
Rudder Stock Seal: 2x China
Fixed Pitch Propeller: 2x Mentrade, Malaysia or Equal, 4 blade manganese bronze, in nozzle
Bow Thruster: 1x Kamome, TFA-50DHN 5T
Thruster Prime Mover: 1x Yanmar, 6HYM-WET 500ps c/w Twin Dise gear box MG 5082 SC (ratio 1.53:1)
AUXILIARY MACHINERIES
Main Generator: 2x CAT, c7.1 150ekw @ 1500 RPM, Heat exchanger cooled, electric start.
Emergency Generator: 1x Cummins, 6BT5.9-GM83 or equal, 58kw alternator @ 1500rpm
Engine Make
Yanmar
Number Engines
2
Accommodation
Berths:
4x One (1) men room
5x Two (2) men room
Berths Total: 14 men
DOMESTIC EQUIPMENTS
Washing Machine: 1 x Midea/Equal, capacity: 10kg
Spin Dryer 1x Midea/Equal, capacity: 6.5kg
4x One (1) men room
5x Two (2) men room
Berths Total: 14 men
DOMESTIC EQUIPMENTS
Washing Machine: 1 x Midea/Equal, capacity: 10kg
Spin Dryer 1x Midea/Equal, capacity: 6.5kg
Berths
14
Safety Gear
FIRE FIGHTING OUTING & LIFE SAFETY EQUIPMENT
CO2 Fire Fighting System: 1 x Fitech Engineering Singapore, Fixed bottle in CO2 room for E/R & B/T compartment, type & capacity to be approved by Class
Fireman System: 13 x China, Fire hydrants and hose per specification
Fireman Outfit: 2 x China, SOLAS standard
Portable Fire Extinguisher: 18 x China, as per Safety Plan
Fire Detection/Alarm System: 1 x Fitech Engineering Singapore, suitable per specification, class approved
Inflatable Rafts: 2 x China, SOLAS standard, 25-man
Life Buoys: 11 x China, SOLAS standard
Life Jackets: 18 x China, SOLAS Standard
Line Throwing: 1 x China, SOLAS standard, 4 projectiles and line
Parachute Distress Rocket: 12 x China, SOLAS Standard
First Aid Kit: 2 x China/Malaysia
Man Overboard Smoke/Light Fittings: 2 x China, SOLAS Standard
Emergency Escape Breathing Devices: 8 x China, SOLAS standard, suitable per the authority
Rescue Boat and Davit Crane: 1 x China, JYHGSR23/16 or Equal 4.5m length x 1.86m breadth x 0.86m depth F. R. P rescue boat capable of carrying 6 persons c/w 40hp Mercury model outboard engine, SWL 21kN
Manhole; 1 x China, , ild steel c/w stainless steel bolt and nuts
CO2 Fire Fighting System: 1 x Fitech Engineering Singapore, Fixed bottle in CO2 room for E/R & B/T compartment, type & capacity to be approved by Class
Fireman System: 13 x China, Fire hydrants and hose per specification
Fireman Outfit: 2 x China, SOLAS standard
Portable Fire Extinguisher: 18 x China, as per Safety Plan
Fire Detection/Alarm System: 1 x Fitech Engineering Singapore, suitable per specification, class approved
Inflatable Rafts: 2 x China, SOLAS standard, 25-man
Life Buoys: 11 x China, SOLAS standard
Life Jackets: 18 x China, SOLAS Standard
Line Throwing: 1 x China, SOLAS standard, 4 projectiles and line
Parachute Distress Rocket: 12 x China, SOLAS Standard
First Aid Kit: 2 x China/Malaysia
Man Overboard Smoke/Light Fittings: 2 x China, SOLAS Standard
Emergency Escape Breathing Devices: 8 x China, SOLAS standard, suitable per the authority
Rescue Boat and Davit Crane: 1 x China, JYHGSR23/16 or Equal 4.5m length x 1.86m breadth x 0.86m depth F. R. P rescue boat capable of carrying 6 persons c/w 40hp Mercury model outboard engine, SWL 21kN
Manhole; 1 x China, , ild steel c/w stainless steel bolt and nuts
Electronics / Navigation
GMDSA Area 3 Radio Console: 1x Oceanlink Engineering Malaysia
Inmarsat C: 1x Furuno Model Felcom 18; LRIT compliance
Inmarsat C (SSAS) 1x Furuno Model Felcom18 SSAS
GMDSS MF/HF Radiotelephone: 1x Icom, GM-800
GMDSS VHF / DSC Transceiver: 1x Icom, GM-600
PA / Talkback System: 1 x Vingtor, CIS Talk Back /. Public Address (PA) System
EPIRB: 1x Jotron, TRON 60
Automatic Identification System: 1 x Koden, KAT-330 Class A
Search and Rescue Radar Transponders: 2 x Jotron, AIS-SART
Primary Radar: 1x koden, MDC-7912P; 64NM
Secondary Radar: 1x Koden, MDC-2040; 48NM
Echo Sounder: 1x Samyung, SES-5000
Speedlog: 1x Simrad, SAL RIA
Gyrocompass: 1 x Anschnutz, Standard 22NX
GPS Navigator: 1 x Koden, KGP-922
Navtex Receiver: 1 x Samyung, SNX-300
GMDSS VHF Portable Radio: 3 x Jotron, TRON TR30
Autopilot System: 1 x Simrad, AP70 MK2
Bridge Navigation Watch Alarm System: 1 x NSR, NBW-1000
Magnetic Compass: 1 x DAIKO, SR-150PPK Reflector compass
Intercom System; 1 x Kocom
Sounpower Telephone: 1 x Vingor, VSP batteryless telephone system
WHEELHOUSE EQUIPMENT
Main Engine Control: 1 x NHK MEC, KE4+, Electronic type control for main engine & bow thruster engine
Twin Engine Telegraph: 1 x CCL, China, light and sound type, 24VDC
Propeller Shaft: 2 x Chine, stainless steel 316
Search Light: 1 x Korea, Remote control, 2000W
Flood light: 8 x China, 400W Halogen type
Navigation Lights: 1 x Korea
Main Switchboard & Distribution: 1 x Malaysia
Electric Air Horn: 1 x Marco, Model: 5423
Wind speed & Direction System (Anemometer): Marinelite, MI9000P
TV Antenna: 1 x Shakespear, 3019
Clear View Screen: 1 X Korea, 300mm, 24v DC
Window Wipers: 2 x China, Straight-line type
Inmarsat C: 1x Furuno Model Felcom 18; LRIT compliance
Inmarsat C (SSAS) 1x Furuno Model Felcom18 SSAS
GMDSS MF/HF Radiotelephone: 1x Icom, GM-800
GMDSS VHF / DSC Transceiver: 1x Icom, GM-600
PA / Talkback System: 1 x Vingtor, CIS Talk Back /. Public Address (PA) System
EPIRB: 1x Jotron, TRON 60
Automatic Identification System: 1 x Koden, KAT-330 Class A
Search and Rescue Radar Transponders: 2 x Jotron, AIS-SART
Primary Radar: 1x koden, MDC-7912P; 64NM
Secondary Radar: 1x Koden, MDC-2040; 48NM
Echo Sounder: 1x Samyung, SES-5000
Speedlog: 1x Simrad, SAL RIA
Gyrocompass: 1 x Anschnutz, Standard 22NX
GPS Navigator: 1 x Koden, KGP-922
Navtex Receiver: 1 x Samyung, SNX-300
GMDSS VHF Portable Radio: 3 x Jotron, TRON TR30
Autopilot System: 1 x Simrad, AP70 MK2
Bridge Navigation Watch Alarm System: 1 x NSR, NBW-1000
Magnetic Compass: 1 x DAIKO, SR-150PPK Reflector compass
Intercom System; 1 x Kocom
Sounpower Telephone: 1 x Vingor, VSP batteryless telephone system
WHEELHOUSE EQUIPMENT
Main Engine Control: 1 x NHK MEC, KE4+, Electronic type control for main engine & bow thruster engine
Twin Engine Telegraph: 1 x CCL, China, light and sound type, 24VDC
Propeller Shaft: 2 x Chine, stainless steel 316
Search Light: 1 x Korea, Remote control, 2000W
Flood light: 8 x China, 400W Halogen type
Navigation Lights: 1 x Korea
Main Switchboard & Distribution: 1 x Malaysia
Electric Air Horn: 1 x Marco, Model: 5423
Wind speed & Direction System (Anemometer): Marinelite, MI9000P
TV Antenna: 1 x Shakespear, 3019
Clear View Screen: 1 X Korea, 300mm, 24v DC
Window Wipers: 2 x China, Straight-line type
Deck Gear
PUMP EQUIPMENT
Bilge & Ballast Pump: 1 x Bombasazcue/Equal, 45m3/hr x 40m
GS/Fire Pump: 1 x Bombasazcue/Equal, 45m3/hr x 40m
Emergency Bilge Pump: 1 x Bombasazcue/Equal, 40m3/hr x 30m
Emergency Fire Pump: 1 x Bombasazcue/Equal, 40m3/hr x 40m
Black Water Pump: 1 x Bombasazcue/Equal, 15m3/hr x 20m
Fuel Oil Transfer Pump: 1 x Koshin/Equal, 9m3/hr x 25m gear pump
Long Range Fuel Oil Pump: 1 x Enga/Equal, 80m3/hr x 50m
Fresh Water Cargo Pump: 1 x Enga/Equal, 50m3/hr x 50m
Fresh Water Transfer Pump: 1 x Euroflo/Equal, 50m3/hr x 50m
FW & SW Pressure set: 2x Neovin/Equal, 5m3/hr x 32 c/w 100ltr tank
FW /SW Standby Set: 1 x Neovin/Equal, 5m3/hr x 32m
Sewage Pump/Grey Water Discharge pump: 1 x Enga/Equal, 15m3/hr x 20m
Dirty Oil Pump: 1 x Koshin/Equal, 5m3/hr x 20m gear pump
AC SW Cooling Pump: 1 x Enga/Equal, 45m3/hr x 30m
SW Cooling Standby Pump: 1 x Enga/Equal, 45m3/hr x 30m
ECR AC Cooling Pump: 1 x Enga/Equal, 25m3/hr x 25m
Wheelhouse AC Cooling Pump: 1 x Enga/Equal, 25m3/hr x 25m
PROV. /REFG. Cooling Pump (chiller freezer): 1 x Enga/Equal, 25m3/hr x 20m
AC Condenser Unit: 1 x Borneo Marine, Malaysia, Marine central air conditioned
Ventilation Fans: 1 x China
Oily Bilge Water Separator: 1 x Han Young, Korea/Equal, HYN00501,0.5m3/hr @ 15ppm, electronic type
Sewage Treatment Plant: 1 x Han Young, Korea/Equal, HYSTPN-014 fir 14 persons
Ballast Water Management System: 1 x Desmi Ocean Guard A/S, Denmark/Equal, CompactClean-85 BWMS Non-Ex, Partly Skid Mounted, Flow rate: 5-85m3/hr
Provision Refrigerating Condenser Unit: 1 x Borneo Marine, Malaysia, Bitzer Semi Hermetic Compressor & Torrent Sea Water Cooled Condenser
Hot Water Calorifier: 1 x Joveb, JH-91
Electric Cooking Range: 1 x SAMJOO/Equal, ER441 4 Square hot plate c/w oven
Food Waste Disposer: 1 x Disperator/Equal, Model: 400
Service Air Compressor: 1 x Jaguar/Equal, capacity 750L/min
Anchor & Chain: 1 x China, 2 x Stockless anchor 2150kg (**) 14 x ?30 mm grade 2steel stud link anchor chain
Hydraulic Ramp & Anchor Winch: 1 x Siong Ping Engineering, Malaysia, HY RAW C30 8T (**) Electro-hydraulic, 8T @ 15M/min c/w 1 gypsy, wire reels & warping drums
Hydraulic Vertical Capstan (AFT): 1 X Siong Ping Engineering, Malaysia, VT SP 3T, electro-hydraulic, 3T @ 10M/min
Bilge & Ballast Pump: 1 x Bombasazcue/Equal, 45m3/hr x 40m
GS/Fire Pump: 1 x Bombasazcue/Equal, 45m3/hr x 40m
Emergency Bilge Pump: 1 x Bombasazcue/Equal, 40m3/hr x 30m
Emergency Fire Pump: 1 x Bombasazcue/Equal, 40m3/hr x 40m
Black Water Pump: 1 x Bombasazcue/Equal, 15m3/hr x 20m
Fuel Oil Transfer Pump: 1 x Koshin/Equal, 9m3/hr x 25m gear pump
Long Range Fuel Oil Pump: 1 x Enga/Equal, 80m3/hr x 50m
Fresh Water Cargo Pump: 1 x Enga/Equal, 50m3/hr x 50m
Fresh Water Transfer Pump: 1 x Euroflo/Equal, 50m3/hr x 50m
FW & SW Pressure set: 2x Neovin/Equal, 5m3/hr x 32 c/w 100ltr tank
FW /SW Standby Set: 1 x Neovin/Equal, 5m3/hr x 32m
Sewage Pump/Grey Water Discharge pump: 1 x Enga/Equal, 15m3/hr x 20m
Dirty Oil Pump: 1 x Koshin/Equal, 5m3/hr x 20m gear pump
AC SW Cooling Pump: 1 x Enga/Equal, 45m3/hr x 30m
SW Cooling Standby Pump: 1 x Enga/Equal, 45m3/hr x 30m
ECR AC Cooling Pump: 1 x Enga/Equal, 25m3/hr x 25m
Wheelhouse AC Cooling Pump: 1 x Enga/Equal, 25m3/hr x 25m
PROV. /REFG. Cooling Pump (chiller freezer): 1 x Enga/Equal, 25m3/hr x 20m
AC Condenser Unit: 1 x Borneo Marine, Malaysia, Marine central air conditioned
Ventilation Fans: 1 x China
Oily Bilge Water Separator: 1 x Han Young, Korea/Equal, HYN00501,0.5m3/hr @ 15ppm, electronic type
Sewage Treatment Plant: 1 x Han Young, Korea/Equal, HYSTPN-014 fir 14 persons
Ballast Water Management System: 1 x Desmi Ocean Guard A/S, Denmark/Equal, CompactClean-85 BWMS Non-Ex, Partly Skid Mounted, Flow rate: 5-85m3/hr
Provision Refrigerating Condenser Unit: 1 x Borneo Marine, Malaysia, Bitzer Semi Hermetic Compressor & Torrent Sea Water Cooled Condenser
Hot Water Calorifier: 1 x Joveb, JH-91
Electric Cooking Range: 1 x SAMJOO/Equal, ER441 4 Square hot plate c/w oven
Food Waste Disposer: 1 x Disperator/Equal, Model: 400
Service Air Compressor: 1 x Jaguar/Equal, capacity 750L/min
Anchor & Chain: 1 x China, 2 x Stockless anchor 2150kg (**) 14 x ?30 mm grade 2steel stud link anchor chain
Hydraulic Ramp & Anchor Winch: 1 x Siong Ping Engineering, Malaysia, HY RAW C30 8T (**) Electro-hydraulic, 8T @ 15M/min c/w 1 gypsy, wire reels & warping drums
Hydraulic Vertical Capstan (AFT): 1 X Siong Ping Engineering, Malaysia, VT SP 3T, electro-hydraulic, 3T @ 10M/min
Survey Details
Basic Function: Transporting Cargo
Classification: Class BV
Descriptive note: Specialized Designed to transport and deliver cargo
Classification: Class BV
Descriptive note: Specialized Designed to transport and deliver cargo
Remarks
DIMENSIONS
Length O. A: 68.00m
Breadth Mld: 16.00m
Depth Mld: 4.50m
Design Draft: 3.594m
Length O. A: 68.00m
Breadth Mld: 16.00m
Depth Mld: 4.50m
Design Draft: 3.594m
CONTACT DETAILS
Dealer
SeaBoats
Geoff Fraser
Geoff Fraser
Telephone
Fax
+64 3337 6259
Address
PO Box 6261
Christchurch Canterbury Australia
Christchurch Canterbury Australia
Website
MORE BOATS FROM SEABOATS
