Pathfinder Pilothouse 17.4 2014 model by Peter Brady
Currency
Length
59' 1" - 18.00m
Vessel Location
Gold Coast QLD
Launch Year
2014
Hull Material
Composite Light weight and Designed to be beached with full keel and protected props
Australian-designed and built late model Power cat.
The philosophy behind the Pathfinder Pilothouse 17.4 was that the systems had to be robust and easy to maintain without getting unnecessarily complicated, and with a backup if possible. This is a boat that is intended to go to sea and stay there for long periods of time, so the systems had to reflect this.
The extra-large rear deck, while at rest, has plenty of room for entertaining 10+ guests. Stepping through the large bi-fold doors into the Saloon on the starboard side and aft Galley on the port side with servery to the rear deck.
Forward, you step up to the pilot house where you, the Captain, can be accompanied by ALL your guests in the comfort of l L-shaped lounges and a second helm chair while cruising. There is also a navigation table port forward.
Stepping down from the pilot house forward are 2 Queen cabins with shared en-suites between the cabins,
The two guest cabins are a Port mid ship double bunk cabin plus a double and single cabin with an ensuite to the starboard side.
Key Points
o Upgrades completed in 2021 and 2023 (ask for extensive list)
o Wireless Yacht controller
o 3000 nm range @ 8 knots
o Accommodation for 10
o Protected props
o Can sit on the sand
A number of different engine options were considered, but Peter Bardy decided to stay with the mechanically injected 440hp
Yanmar 6LY3-STP's that have been used in his previous custom builds.
Reasons for choosing this engine;
o Highest power-to-weight ratio in their class
o Very narrow, which suits a catamaran hull
o They are a pure marine engine
o Equipment such as oil filters is positioned on top to make them easier to service.
o They have Mechanical injection, which is more forgiving to fuel quality, which can be a problem when cruising to more remote places.
o These engines are electronically controlled for higher torque and a cleaner fuel burn, and this allows the engine's operating data, such as temperature, pressure and fuel consumption, to be displayed on an LCD screen.
o Both the engines and gearboxes are from Yanmar; warranty and matching the correct type is less of an issue, and in this installation, the gearboxes are 2.47:1 with an 8° down angle.
Call Jules on
The philosophy behind the Pathfinder Pilothouse 17.4 was that the systems had to be robust and easy to maintain without getting unnecessarily complicated, and with a backup if possible. This is a boat that is intended to go to sea and stay there for long periods of time, so the systems had to reflect this.
The extra-large rear deck, while at rest, has plenty of room for entertaining 10+ guests. Stepping through the large bi-fold doors into the Saloon on the starboard side and aft Galley on the port side with servery to the rear deck.
Forward, you step up to the pilot house where you, the Captain, can be accompanied by ALL your guests in the comfort of l L-shaped lounges and a second helm chair while cruising. There is also a navigation table port forward.
Stepping down from the pilot house forward are 2 Queen cabins with shared en-suites between the cabins,
The two guest cabins are a Port mid ship double bunk cabin plus a double and single cabin with an ensuite to the starboard side.
Key Points
o Upgrades completed in 2021 and 2023 (ask for extensive list)
o Wireless Yacht controller
o 3000 nm range @ 8 knots
o Accommodation for 10
o Protected props
o Can sit on the sand
A number of different engine options were considered, but Peter Bardy decided to stay with the mechanically injected 440hp
Yanmar 6LY3-STP's that have been used in his previous custom builds.
Reasons for choosing this engine;
o Highest power-to-weight ratio in their class
o Very narrow, which suits a catamaran hull
o They are a pure marine engine
o Equipment such as oil filters is positioned on top to make them easier to service.
o They have Mechanical injection, which is more forgiving to fuel quality, which can be a problem when cruising to more remote places.
o These engines are electronically controlled for higher torque and a cleaner fuel burn, and this allows the engine's operating data, such as temperature, pressure and fuel consumption, to be displayed on an LCD screen.
o Both the engines and gearboxes are from Yanmar; warranty and matching the correct type is less of an issue, and in this installation, the gearboxes are 2.47:1 with an 8° down angle.
Call Jules on
Price
AU $2,200,000 Make an offer
Vessel Name
SALUTE
Boat Reference
JULES0033
Launch Year
2014
Length
59' 1" - 18.00m
Beam
6.7m
Draft
1.1m
Displacement
21000kg
Vessel Location
Gold Coast Qld
Region
Queensland
Use
Family, Leisure, Cruising
Designer
Peter Brady
Builder
Pathfinder Marine
Hull Material
Composite Light weight and Designed to be beached with full keel and protected props
Decks Material
Composite
Engine
Twin Yanmar 6LYA-STP, Yanmar Gearbox's 2.47:1 reduction Bi rotational serviced 20 hrs ago
Engine Make
Yanmar
Number Engines
2
Horsepower
440 x 2
Fuel Type
Diesel
Engine Hours
2400 as at 15/09/2025
Engine Hours (2nd Engine)
2400 as at 15/09/2025
Fuel Consumption
70lph @ 16 knots Cruise 1200nm range. 27lph @8 Knotts 3000 nm range
Max Speed
24
Cruise Speed
Extended range speed is 8 knotts, fast cruise 16-18 knots
Propulsion
Props: 2x 4 blade 26x26" Shaft: 56mm 2201 stainless steel with isoflex cupplings
Thrusters
Bow Thruster
Genset
Seawasp 12 KVA 140 hrs on it and serviced 20 hrs ago as at 15/09/2025
Fuel
2 x 2700
Water
2 x 250 litre and 2x 500 litre
Dinghy
3.8 m Highfield Rib
Outboard
30 hp 2 stroke Tohatsu outboard
Cabins
2 Queen cabins with shared en-suites between the cabins,
The two guest cabins are a Port mid ship double bunk cabin plus a double and single cabin with an ensuite to the starboard side.
The two guest cabins are a Port mid ship double bunk cabin plus a double and single cabin with an ensuite to the starboard side.
Berths
7
Shower
3 showers, one on the Main deck opposite the Galley, one as an ensuite to the 2 forward queen cabins
Toilet
2 Techma large bowl electric
Air-Con
Marine-air 240v to each cabin
Refrigeration
Double Door ridge/freezer
Freezer
In fridge and extra fridge/freezers down stairs and on rear deck
Stove
Smev 3-burner gas top
Water-Maker
Stella 210 lph Compressor:
Hot Water
1 x 70 lt isotherm
Electrics
Lighting System: Full led lighting throughout
Shore Power: 240 V
Inverter: 2 x Victron 3000 watt inverter/Charger
Batteries: House 3 x Mastervolt 400ah lithium batteries with all the safeguards built in, 2 x 150 ah start, 1 x 70 ah genset, 2 x 150 ah anchor winch AGM-type batteries.
Solar Panels: 1800-watts of solar panels with regulator
Shore Power: 240 V
Inverter: 2 x Victron 3000 watt inverter/Charger
Batteries: House 3 x Mastervolt 400ah lithium batteries with all the safeguards built in, 2 x 150 ah start, 1 x 70 ah genset, 2 x 150 ah anchor winch AGM-type batteries.
Solar Panels: 1800-watts of solar panels with regulator
Electronics / Navigation
GPS: Simrad
Plotter: Simrad
Sounder: Simrad
Radar: Simrad 3 kw
Auto Pilot: Simrad Wind Instruments
Plotter: Simrad
Sounder: Simrad
Radar: Simrad 3 kw
Auto Pilot: Simrad Wind Instruments
