Riviera 505 SUV

SWAN MARINE is excited to present to the market is this stunning 2023 Riviera 505 SUV Platinum Model, featuring impressive specifications and luxurious upgrades.
Powered by twin Volvo D11 IPS 950 engines with low hours, this yacht promises both efficiency and performance.
Riviera is synonymous with the Australian way of life. Built on our shores this vessel is one of the finest boats to leave the Riviera production line.
This beautiful vessel boasts too many features to mention. From gaping sunroof to the CZone digital control and monitoring system. This vessel has everything. Literally.

ENGINES:
Engines - Twin Diesel - Volvo D11 IPS 950 (533kw/725hp)
- 1 x twin lever electronic control (helm)
- 3 x joysticks (one at helm, two at Cockpit)
- Volvo DPS (Dynamic Positioning System)
- autopilot
- low speed mode
- Volvo Penta IPS propulsion units (x2)
- Line cutters between props
- Propellers x 4,1 x nibral four blade and 1 x nibral three blade counter rotating, port and starboard
- Volvo active corrosion protection (ACP) system
Interceptors - Volvo Interceptor System with manual controls to helm
Auto Trim and List to Volvo Interceptor System
Volvo Penta Easy Connect, for remote app-based monitoring and recording of engine data
Seakeeper

ELECTRONICS:
Cockpit - docking station, including joystick engine control with start stop control panel
Czone - Configuration for iPad connectivity. Includes programming and Wi-Fi interface
GARMIN
Screens
2 x 17" Glass Bridge 8617 inc GPS & GRID controller
Sounder/Transducer CHIRP
Garmin GSD 26 CHIRP Sounder with 1kW
B275LHW depth/temp transducer
Sounder/Transducer ClearVu/SideVu
Garmin GSD 25 CHIRP sounder with GT51M
THP ClearVu SideVu 500W and traditional
600W transducer
Sounder/Transducer Panoptix
Radar
GMR Fantom CHIRP 24 Closed Array Radar
Seaview mount 48nm

CONSTRUCTION:
Acoustic and thermal insulation linings to engine room and machinery spaces
All exterior stainless-steel mirror finish with ground and polished welds 316 marine grade
All through hull fittings on or below the water line fitted with composite ball valves, all hoses double clamped
Forward hull compartment foam filled for added strength and noise dampening, where possible
Hand laid, moulded fibreglass hull, cored deck & hull topsides
Independent compartments throughout hull
Isophthalic gelcoat exterior (white)
Solid GRP keel and chines
Vinylester resin in first outer layer of hull
Watertight collision bulkhead forward
Infused Vinyl Ester hardtop

SWIM PLATFORM
Hydraulic lift swim platform GRP (up/down) 350kg with fixed hob section (boat trim & performance will be affected) comes with fitted tender and engine.

REAR AWNING
Half rear cockpit awning (800mm from aft of hardtop), including fixed, single bow stainless steel frame and acrylic canvas cover

SALOON
Air conditioning with electric heat 2 x 16000 BTU (split to galley)
Flooring, vinyl (premium grade)
Grabrail recessed into headliner
Head lining, vinyl with padding
Overhead lighting - LED
Port lounge with drawer storage below
Side windows - Glass, opening (sliding)

GENERAL SPECIFICATIONS
Anchor chain chafe plate fitted to bow
Anchor chain safety stopper fitted to deck
Anchor locker with rope/chain divider (o set to stbd). Access from hatch on deck
Antifouling: 2 coats epoxy undercoat, 2 coats antifoul with Propspeed coating to propellers & Pod Drive gear
Anchor winch vertical with overload protection circuit breaker, suit rope & chain, hand held remote to bow & remote incorporating chain counter to helm
Bow rail welded stainless steel (316 marine grade, highly polished) with mid safety wire including flag staff and burgee (bow flag)
Bow roller stainless steel self-loading - through bow, heavy duty
Cleats - stainless steel, 9x11" cleats and 2 x forward deck fair leads
Fenders x 4, dock lines x 3 and boat hook
Gelcoat - 1 litre, shipped on board
Owner's manual - High quality, water resistant and comprehensive
Rub rail - impact and UV resistant PVC (white) with stainless steel insert strip
Wash down outlets at anchor locker - salt & fresh water
Three joysticks for easy manoeuvrability

MECHANICAL
Bilge pumps - auto and manual override x 4
Double action manual bilge pump for engine room fitted to port side transom locker
Engine mounts - anti vibration
Engine room access with stainless steel ladder
Engine room flow coated white
Engine room lighting LED (DC) x 6
Engine room ventilation system air intakes with mist eliminators and forced air out system
External & internal seawater strainers for main water intakes- engines, generator & air conditioning
Fresh water tap & hose set in engine room
Fresh water heater AC 45L (11.8 US gallons)
Fresh water system (pressurised) total capacity 460 Litres (121 US gallons)* (approx), tank level indication on CZone
Fuel filler to port
Fuel tank monitoring within MAN Engines or Volvo system
Fuel tank, GRP, coated in re retardant resin. Total 3,300 litres (898 US gallons) *(approx. )
Fuel filter/ water separator for engines & generator
Fuel lines all swaged
Vacuush sanitation system, tank level indication on CZone control panel with overboard pump out and deck fitting for dockside pump out

ACCESSORIES
Siren Marine Remote Monitoring system including Bilge monitoring for 2 wireless bilge pumps, wired Motion and wireless Temperature sensors for Saloon, House battery charger (shore power present) monitoring, House battery voltage monitoring (12V emergency bank on applicable boats), GPS location, tracking and geo-fence, 3 standard wired circuit controls (Cockpit Lights, Saloon Lights, Saloon air Conditioning) First 24 month subscription free (ongoing subscription thereafter at owners discretion, Siren marine will contact owner) Note: Siren Marine network dependant on region.
Teltonika 3G/4G Modem connected to onboard WiFi including dual 4ft antennas to Hardtop
Loudhailer connected to VHF (Speaker only, not 2 way communications) (Communications)
Connect Navigation Display to Saloon TV (Accessories & Satellite TV )

Like mentioned above, there are too many extras to mentions.
If you would like to know more about the specifications or to view this stunning vessel, please call TIM SWAN on Call Seller
