Catalina 30 Cruising Yacht
Currency
Length
30' - 9.14m
Vessel Location
Coomera QLD
Launch Year
1986
Hull Material
Fibreglass/GRP
"Fujimo" is an excellent example of the well renowned Catalina 30 MKII. Over 7000 of these fabulous American yachts built for a good reason. "Fujimo" offers huge internal volume and living spaces with her 10'8" beam and 6'+ headroom, she has an easily driven hull and with her hydro dynamic fin keel and rudder, she performs well on all points of sail. They were the most spacious yacht in their class for decades.
When the sails are down, you can rely on the smooth performance and dependability of a high-quality 21hp Nanni diesel engine, installed new in 2021, capable of propelling her up to 7 knots.
Inside, she boasts a simple yet elegant cabin layout, featuring a large double berth beneath the cockpit, a spacious saloon with a drop-down table, and a comfortable forward double V-berth with an ensuite bathroom, complete with an electric head and shower.
- Fujimo has had some major upgrades:
- Mast repainted and all fittings removed and replaced 2022
- New standing rigging 2022
- New fully battened mainsail 2022
- New Nanni three cylinder diesel with low hrs (2021)
- New Hot water system (1 shower old)
- Completely rewired & new Raymarine electronics package
- New LED lighting & fans
- Raymarine VHF
- LED lighting
- New electric winch 2021
- New front opening fridge under the stove.
This is the perfect single hander's yacht for bay or coastal use.
Price
AU $59,900 No more to pay - sail away
Vessel Name
Fujimo
Boat Reference
S5454
Launch Year
1986
Length
30' - 9.14m
Beam
3.3m
Draft
1.61m
Displacement
4627kg
Keel / Ballast
Fin keel fastened to the hull by 8 x 1" stainless bolts and the keel is lead cast ballast.
Vessel Location
Coomera Qld
Region
Queensland
Use
Family, Leisure, Cruising
Registration
JV824Q
Designer
Gerry Douglas
Builder
Catalina Yachts USA
Hull Material
Fibreglass/GRP
Decks Material
Fibreglass / GRP
Engine
* New 21hp Nanni N 3.21,3 cylinder, 1" shaft drive diesel Serial Number KTC20073317 ( fitted by CME Marine April 2022)
* Propellor is three blade 14"
* Shaft is supportd by a bronze P bracket and is fitted with a Volvo dripless shaft seal
Engine Make
Nanni
Number Engines
1
Horsepower
21hp
Fuel Type
Diesel
Fuel Consumption
1.5 L/hr
Max Speed
7 knots
Cruise Speed
5 knots
Propulsion
13" 3 blade
Fuel
Single aluminium diesel tank located under the companionway steps, capacity 65 litres
Water
Two Polypropylene water tanks located under each saloon settee, total 145 ltrs.
Covers
Bimini & dodger
Accommodation
- Double V- berth fwd
- Double berth starboard aft under cockpit
- Saloon/table midships converts into additional double
- Single pilot berth to starboard in the saloon
- Double berth starboard aft under cockpit
- Saloon/table midships converts into additional double
- Single pilot berth to starboard in the saloon
Cabins
2 x double berths with optional extras in drop-down saloon table and pilot berth
Berths
Up to 7
Shower
Enclosed hot/cold
Toilet
Electric head with holding tank 66 ltrs
Entertainment
* 1 x TV
* Stereo with marine speakers
* Stereo with marine speakers
Galley
* Located to port aft, it has twin s/s sinks
* Pressure hot and cold water
* Butane single burner stove
* Lots of bench top space and cupboards
* Pressure hot and cold water
* Butane single burner stove
* Lots of bench top space and cupboards
Refrigeration
Large benchtop fridge in galley
Stove
Portable butane stove
Hot Water
Duetto 12 V
Ground Tackle
* Maxwell winch with wireless remote
* Manson 35lb Plough anchor with swivel and 40 M x 8mm chain
* Manson 35lb Plough anchor with swivel and 40 M x 8mm chain
Safety Gear
* Life jackets
* Epirb
* Flares
* Fire extinguishers
* Emergency tiller
* Epirb
* Flares
* Fire extinguishers
* Emergency tiller
Bilge Pumps
Rule 2000 Electric bilge pump with automatic float
Epirb
Yes
Life Jackets
4
Flares
Coastal pack
Fire Protection
3 x 1 kg Portable extinguishers, fire blanket
Electrics
* 1 x 150 Watt Solar panel woith MPPT regulator
* 12 v DC rewired by ADL Marine 2022
* Victron 12 V 1500w Inverter/ 70 amp Charger
* 2 x Cafrimo Fans
* LED lighting
* Two new 6 volt Lifeline 225 amp sealed batteries and one 12 volt
battery for engine cranking
* Battery Mounting : Securely mounted in individual plastic boxes
* 12/240 V Duetto hot water system
* 240 V shore power system fitted with a Clipsal IP 56 inlet and an RCD circuit breaker
* 12 v DC rewired by ADL Marine 2022
* Victron 12 V 1500w Inverter/ 70 amp Charger
* 2 x Cafrimo Fans
* LED lighting
* Two new 6 volt Lifeline 225 amp sealed batteries and one 12 volt
battery for engine cranking
* Battery Mounting : Securely mounted in individual plastic boxes
* 12/240 V Duetto hot water system
* 240 V shore power system fitted with a Clipsal IP 56 inlet and an RCD circuit breaker
Electronics / Navigation
* Raymarine Axiom Pro (New 2021)
* Raymarine DST 800 transducer
* Raymarine Autopilot Remote
* Raymarine Wind Instruments
* Raymarine i60wind display
* Raymarine ITC-5 module
* Raymarine VHF
* Raymarine DST 800 transducer
* Raymarine Autopilot Remote
* Raymarine Wind Instruments
* Raymarine i60wind display
* Raymarine ITC-5 module
* Raymarine VHF
Sail Inventory
* New fully battened mainsail (2022)
* Furling genoa
* Storm jib
* Furling genoa
* Storm jib
Mast / Rigging
* Mast taken out and refurbished (2022)
* New standing rigging (2022)
* Painted Aluminium mast & boom
* New standing rigging (2022)
* Painted Aluminium mast & boom
Deck Gear
* 2 x 40 Lewmar winches
* 2 x 16 Lewmar winches
* Moulded Aluminium toe rail
* Stainless boarding ladder
* 2 x 16 Lewmar winches
* Moulded Aluminium toe rail
* Stainless boarding ladder
Remarks
If you are looking for a spacious, easy to sail well maintained and recently upgraded 30' yacht that has the space of a 35' yacht, look no further...
CONTACT OUR OFFICE: (07) 5502, Sam Martel or Ian Mackenzie to arrange an inspection in our hardstand sales area at The Boat Works.
DISCLAIMER: The company offers the details of this vessel in good faith but can not guarantee or warrant the accuracy of this information, nor warrant the condition of the vessel. A buyer should instruct his surveyor to investigate such details as the buyer desires. This vessel is offered subject prior to sale, price change, or withdrawal without notice.
CONTACT OUR OFFICE: (07) 5502, Sam Martel or Ian Mackenzie to arrange an inspection in our hardstand sales area at The Boat Works.
DISCLAIMER: The company offers the details of this vessel in good faith but can not guarantee or warrant the accuracy of this information, nor warrant the condition of the vessel. A buyer should instruct his surveyor to investigate such details as the buyer desires. This vessel is offered subject prior to sale, price change, or withdrawal without notice.
