Swanson 38 Masthead sloop yacht, spoon bow, canoe stern
Currency
Length
38' - 11.58m
Vessel Location
MONA VALE NSW
Launch Year
1981
Hull Material
Fibreglass/GRP
Arguably one of the finest examples of this superb design. Outstanding factory fitout in Doug Brookers Custom Yachts factory by Keith Newland 6000 hours. Hull built above designers specification.
Australian registration certificate No 852848.
We have been the caretakers of MYRA since 1998 and had many holidays over the 28 years. MYRA has always been maintained to a high standard. Please enjoy looking at her photos.
Myra comes complete with many spare and service items including spare Propeller/Shaft/bearing.
survey now attached see PDF file
Australian registration certificate No 852848.
We have been the caretakers of MYRA since 1998 and had many holidays over the 28 years. MYRA has always been maintained to a high standard. Please enjoy looking at her photos.
Myra comes complete with many spare and service items including spare Propeller/Shaft/bearing.
survey now attached see PDF file
Price
AU $69,000
Vessel Name
MYRA
Launch Year
1981
Length
38' - 11.58m
Beam
11 foot 3 inch's
Draft
5 foot 6 inch's
Displacement
9.5 tons
Keel / Ballast
3/4 keel internal lead ballast
Vessel Location
Mona Vale Nsw
Region
New South Wales
Use
Cruising
HIN
AUWWA054724A68
Registration
MYRAn
Rego Expiry
27/11/2026
Designer
Ron Swanson
Builder
Swanson Brothers / Keith Newland @ Doug Brookers Custom Yachts
Hull Material
Fibreglass/GRP
Decks Material
Timber Celery top pine for and aft planks and planks at 45 all encapsulated fibreglas
Engine
ST W3 serial number 516000.168 3 cylinder 30HP marine motor with hydraulic gearbox with
Morse controls. Oil cooler and permant sump suction pump fitted for easy service and oil filter replacment.
Spares include gasket sets, filters, fuel pump, water pump, injector pump etc
Engine Make
Lister
Number Engines
1
Horsepower
30 hp
Fuel Type
Diesel
Engine Hours
1680
Fuel Consumption
2L per hour
Max Speed
6 knot
Cruise Speed
5 knot
Propulsion
Inboard Shaft Drive : Hydralign feathering 3 blade propeller AA39877 and shaft by JBC yacht Engineering
Genset
Honda 1kv portable
Fuel
250 litters
Water
3 tanks ( 65 gal ) ( 30 gal ) (25 gal )
Dinghy
Yes
Outboard
3hp Mercury
Covers
Full boat covers, hatch covers, sun cover, boom cover, etc covers for everything
Accommodation
V berth- cabin berth- 1/4 berth
Berths
4 Berths
Shower
2 ( 1in head -1in cockpit ) engine heat exchange / 240v hot water
Toilet
Yes manual with holding tank
Air-Con
No
Galley
Sink, cooker, fridge and work space
Refrigeration
Eutectic with 134a gas, large stainless steel custom built fridge/freezer
Stove
Maxi 3 burner metho
Water-Maker
No
Hot Water
Yes
Ground Tackle
Maxwell-nielson electric winch - anchor chain - nylon rope 2 galvanised anchors
Safety Gear
Harness
life ring
man overboard retrieval
V sheet
life ring
man overboard retrieval
V sheet
Bilge Pumps
2 Henderson manual in cockpit - 2 Rule electric in bilge
Life Jackets
Yes 8
Fire Protection
Fire blanket CO2 and powder
Electrics
12v starting battery
12v house battery
500 watt inverter
2 solar panels with regulators
12v house battery
500 watt inverter
2 solar panels with regulators
Electronics / Navigation
Furuno GPS
Brooks and gatehouse instruments, auto pilot, electronic Compass, etc
Pedestal Compass
Davis mk 25 sextant
Fuj ion f200 direction finder
Icom M700 HF
Sailor VHF
Pulsotronic battman 2
Brooks and gatehouse instruments, auto pilot, electronic Compass, etc
Pedestal Compass
Davis mk 25 sextant
Fuj ion f200 direction finder
Icom M700 HF
Sailor VHF
Pulsotronic battman 2
Sail Inventory
Scott Genoa very good, Scott Furling head sail with uv protection as new, Scott battoned jib very good, Sobsted mainsail with reef points good, Trisail and jib, Older set of hood sails 1,2,3. All sails are dacron.
Mast / Rigging
Timber mast with stainless steel spreaders removed in 2020 stripped, epoxy and ALGRIP system all standing rigging and ronstan rigging screws replaced, alloy pole. All standing rigging replaced with 10mm 1 x 19 Powerflex ( Compact Strand ) MBL 9,800 Kgl, Swage eyes 10mm x 5/8 MBL 10,200 Kgl, Swage Stud 10mm MBL11,800 Kgs, Swage Toggie MBL10,900 KGL, Rigging Screws Rhonstan 10mm x 5/8 MBL8670 KGL, all done April 2020 by ( Greg Arcus ) ROPE & CABLE.
Deck Gear
5 self tailing winches cockpit 3 winchs on mast
boom brake
many pulleys etc all good
boom brake
many pulleys etc all good
Remarks
38 cruising yacht, mast head rig, spoon bow, canoe Stern and long keel. Exceptional in quality of construction and general condition.
I have access to Slipway and can arrange an out of water inspection on application.
I have access to Slipway and can arrange an out of water inspection on application.
