Nordhavn 96


Price
US $8,995,000
Currency
Length
96' - 29.26m
Vessel Location
Rose Bay NSW
Launch Year
2017
Hull Material
Fibreglass/GRP Full displacement hull designed for ocean passages

In 2017, Pacific Asian Enterprises (PAE) expanded their Nordhavn line with the addition of the Nordhavn 96. Being well received by the exploration yacht community, the Nordhavn 96 won the 2017 International Yacht and Aviation Award. This new design bridged the gap between the large cruising exploration yacht and super-yacht categories. She was designed for the yachting enthusiast who seeks the super-yacht comfort and style in a boat that is still able to be managed with no or minimal crew, and travel big open oceans. The 96 series is based on the hull of the very successful Nordhavn 86, while incorporating a larger cockpit, lazarette, and better crew space below deck. The greater volume is also felt on the main deck level, in the dining and galley areas, and on the pilothouse deck with a large upper master stateroom. The greater length also allows for a more spacious fly bridge with hot tub. Lacey Kay was built by her current owner, making frequent trips to the yard during the build process. He opted for the additional fuel tanks, giving her an aggregate capacity of 9,575 gallons. With her increased waterline hull length, her fuel burn was actually slightly reduced from the 86. At her most efficient cruise speed of 9 knots, she burns about 10 gallons per hour per side, plus 5 gallons for the house generator, giving her an approximate 4,000 NM range; well enough for a Pacific crossing. According to Jeff Leishman, PAE's Chief of Design, extending her hull length has allowed Nordhavn to enhance the performance of, and increase stability and comfort in this well-proven hull design.


Price
US $8,995,000
Vessel Name
Lacey Kay
Boat Reference
NLK96
Launch Year
2017
Length
96' - 29.26m
Beam
7.32m (24ft)
Draft
2.49 m (8 ft 2 in)
Displacement
Approx. 181.44 metric tons (400,000 lbs)
Vessel Location
Rose Bay Nsw
Region
New South Wales
Use
Family, Leisure, Cruising
Designer
Nordhavn Yachts
Builder
Nordhavn Yachts
Hull Material
Fibreglass/GRP Full displacement hull designed for ocean passages
Decks Material
Fibreglass
Engine
Twin Caterpillar C18 ACERT diesel engines
Engine Make
Caterpillar
Number Engines
2
Horsepower
715 hp each (1,430 hp total)
Fuel Type
Diesel
Engine Hours
Approx. 2,330 hours
Engine Hours (2nd Engine)
Approx. 2,330 hours
Fuel Consumption
Approx. 15-20 GPH at cruising speed
Max Speed
12 knots
Cruise Speed
10 knots
Propulsion
Shaft drive
Thrusters
Hydraulic bow and stern thrusters (ABT Trac)
Genset
Twin Northern Lights 55 kW generators
Fuel
9,575 gallons (approx. 36,245 litres)
Water
985 gallons (3,729 liters)
Dinghy
Custom tender stored on the upper deck
Covers
Protective covers for exterior seating and helm stations

Covers for tenders and equipment stored on deck

UV covers or shades for windows or flybridge areas
Accommodation
Guest Capacity: Up to 9 guests
Cabins
Guest Cabins: 5 staterooms

Owner's Cabin: Upper deck owner's cabin

VIP Suite: Full-beam VIP suite

Convertible Cabins: 2 convertible doubles

Crew Capacity: 5 crew members

Crew Cabins: 3 cabins, including a pilot's cabin with a single
Berths
9 guests in 5 staterooms
Shower
Five guest staterooms is equipped with its own en-suite bathroom, which includes a shower.
Toilet
Each cabin is equipped with its own en-suite bathroom, providing privacy and convenience for all guests and crew members.
Entertainment
Guest Cabins: Each cabin has its own entertainment center

Common Areas: Spacious saloon and upper deck areas for relaxation and socialising
Air-Con
Equipped with a comprehensive air conditioning system, ensuring comfort throughout the vessel.
Galley
The galley is designed for both functionality and comfort, featuring modern appliances and ample storage to support extended voyages. It includes a coffee machine, wine cooler, ice maker, trash compactor, full-sized dishwasher, oven, hob, and extractor fan, mirroring the capabilities of a high-end residential kitchen.
Refrigeration
Significant refrigeration capacity, including units integrated into the cockpit bar area.
Freezer
Dedicated freezer units are included
Stove
The galley is equipped with a high-quality stove, suitable for preparing meals during extended voyages.
Hot Water
The yacht is equipped with a hot water system to provide comfort during extended stays.
Ground Tackle
Anchor Windlasses: Two Maxwell VWC 6000 hydraulic windlasses with controls located in the pilothouse and on the foredeck, each equipped with chain counters.

Anchors: Two 300 lb. Stainless steel anchors.

Anchor Chains: Port side features 700 feet of 5/8" stud link chain; starboard side has 400 feet of the same.

Mooring Capstans: Two Maxwell VC 3000 electric mooring capstans located at the stern.

Anchor/Chain Washes: High-capacity systems installed for both anchors.
Bilge Pumps
Integrated hydraulic bilge pumps
Life Raft
Yes
Fire Protection
Includes an automatic fire suppression system in the engine room and lazarette
Electrics
Universal AC electrical system (shore power adaptability)
