Nautor Swan 58

Fine Example of this model
Fully equipped and turn-key ready
Video tours available on request
This Nautor Swan 58-015 'Coco' benefits from the most popular three cabin layout with a double ensuite master, double guest and twin en suite guest cabin. The boat has been highly specified and set up so it can easily be handled by a couple. It features many options extras including Hall Spars Carbon rig, additional hull windows, bow and stern thrusters, Air conditioning, Water maker, Generator to name just a few items.

Quick overview of additions to standard factory specifications:    Metallic Paint Upgrade - Dark Neutral Grey
   Teak on Coachroof and Decks
   Additional hull windows in forward owners cabin and aft cabins
   Carbon Wheels - carbon composite steering wheels in satin finish with teak inserts
   Harken CLR600 Mooring Winch
   Stern Thrusters and Bow Thrusters
   Passerelle Carbonautica 2,3 m
   Schenker Smart 100 Watermaker
   Sea & Fresh Water Toilet Flushing System
   Second fridge / freezer portside bench-top forward (3 in total)
   Air Conditioning in all cabins - Climma DC35 RC
   Service battery upgrade to a Lithium-Ion - 800Ah
   Inverter Upgrade
   Generator Upgrade - Whisper Power 12kW 2800rpm generator
   Electric Stove - Induction 3-burner
   Washing / Drying Machine
   Complete B&G Navigation package
   Peplink Internet 4G System
   Mini VSAT, KVH TracPhone V30
   Hall Spars Carbon Mast and Boom
   EC-3 Carbon Rigging
   Self Tacking System for Staysail
   Seldén Electrical Jib Furler
   Staysail Hydraulic Tensioner
   Captive Mainsheet Winch
   Upgraded running rigging
   Full Batten Mainsail 3Di OCEAN 700
   Furling Jib 3Di OCEAN 700
   Selftacking Furling Jib 3Di OCEAN 700
   Aft Port Toilet converted to Workshop and Storage for Tools etc
   TruKit 2.8m cameraman tender with Yamaha 6HP outboard
   Extensive safety equipment
   Full set of tools and spare parts Powered by North Sails 3Di Ocean 700 sails, Hall Spars carbon fibre mast and boom, head sail electric furler and EC3 carbon rigging, this Swan 58 is equipped with over 250k Euro of high-standard Nautor Swan owner options/extras.

The Swan 58 has a well-proven and successful canoe body design concept; powerful, well-balanced and sea kindly shape that would be safe and a pleasure to sail. A true Blue Water yacht intended to sail in comfort anywhere in the world, the forward sections have been softened with the idea of giving her a softer ride upwind against the sea normally encountered in force 4/5 wind conditions. The final length was settled after a thorough study of the interior volume of this new model, as required to fit three full-size cabins on this Swan 58. There is a comfortable saloon, and ample galley, together with the space necessary to fit all the complements and machinery required by today's high standards of living. Thanks to the relatively long coach roof, large window areas, numerous hatches, the hull ports and full headroom throughout there is a feeling inside the 58 of being in a much larger luminous, well-ventilated yacht. On the other hand, the freeboard is lower than the norm. She is elegant and sleek. The anchor on this Nautor Swan 58 is stowed on the integral bowsprit and the windlass on a special watertight compartment below deck. On deck there is the typical array of winches close to the cockpit and the double steering positions on this Nautor Swan 58. The cockpit sports twin tables surrounded by more than 2 meters long L-shaped settees. At the forward end of the uncluttered coach roof there is a dedicated sun-bed.

DimensionsLength of hull - 17.96m / 58.92ft LOA - 19.11m / 62.70ft LWL - 17.09m / 56.07ft Beam max - 5.27m / 17.29ft Draught - 2.70m / 8.86ft Displacement - 25400kg / 56000lbs Ballast (keel) - 7500kg / 16540lbs Engine - Volvo 4LV 150Hp Generator - Whisper Power 12kw Service batteries - Lithium-Ion Victron Smart LiFePO4 25.6v 800Ah Fuel Tanks - 1080 litres Water Tanks - 950 litres Bow and Stern Thrusters - Side-Power Proportional
HullSwan 58 Standard Hull - 3 Cabin Layout
Antifouling
Metallic Paint Upgrade Dark Neutral Grey DM384
Hull Line in Steel Grey Metallic MB2852
Coaming Stripe in Metallic Dark Neutral Grey DM384
Teak on Coachroof and Decks
Caulking in Grey
Additional hull windows in forward owners cabin and aft cabins
Carbon Wheels - Isotop five spoke 1050 mm carbon composite steering wheels in satin finish with teak inserts
Anchoring & DockingAnchor Upgrade to 45kg Ultra, Upgraded Bowsprit, Fairleads
Harken CLR600 Mooring Winch
Stainless Anchor Chain 100m CROMOX CXI-10 AISI 318LN Duplex stainless steel electro polished
Stern Thrusters and Bow Thrusters
Passerelle Carbonautica 2,3 m
Remote Control for Transom Door
Windlass remote on pedestal
FenderTex docking fenders x 12 with electric inflator
Boat hooks x 2
6 x docking lines
Spare anchor  Fortress FX-85 with 10m chain and 100m rope
Lifting strop for securing aft to shore via line
Canvas WorkCockpit Cushions (including sunbathing on table)
Winch covers
Cockpit Table Covers (pockets on each end for storage)
Pedestal and Wheel Covers
Mainsail Cover x 2
SunSmart Bimini
Crew Cover for Saloon Table & Nav Station
Cover for lazarette when open
Upgraded Spray Dodger
PlumbingWatermaker Schenker Smart 100 Digital modular, 17.900 24VDC with a capacity of 100L/h, 2400L/day.
Fresh Water Outlets Forepeak & Cockpit
Sea Water Outlets Forepeak & Cockpit with Hose with pressurised sea water system
Sea & Fresh Water Toilet Flushing System
Second fridge / freezer portside bench-top forward (3 in total)
ElectricalAir Conditioning in all cabins - Climma DC35 RC
Inverter Upgrade to work with larger Genset and shore[owner upgrade to 50A
Service battery upgrade to a Lithium-Ion Victron Smart 25.650 LiFePO4 Battery 25,6V 800Ah/3,3h
Generator Upgrade - Whisper Power M-GV15 Piccolo 230V 3.650 12kW 2800rpm generator
Fans in Aft Cabins & Master
Electric Stove - Induction 3-burner, GN Espace Ocean 3.900 chef 3,230V
Microwave (Siemens)
Washing Machine - LG 7 kg washing capacity, 4 kg drying capacity
Red Night Lights in all cabins
Interior Lighting Upgrade (Saloon)
Tricolour on Masthead - Lopolight 360
Spreader Uplights
Cockpit Lighting
Boomlights - 2 Additional
Engine Data Monitor (to display engine performance on B&G)
Digital Display for Freezer
Master Bedroom Lighting Upgrade
Lighting in aft cabins upgrade
Additional Power outlets internal (230v & USB)
Shore power cable 10m + 15m
ElectronicsB&G in Master Cabin (Zeus 7")
AIS - Class B AIS (SOTDMA) transponder, B&G V3100 including GPS and VHF antenna splitter, B&G NSPL- 500
B&G on Pedestals - Zeus3S 12 inch multifunction displays
Radar - HALO24 compact 24-inch dome
B&G at Nav Station - Zeus3S 12 inch multifunction display
Forward-looking sonar B&G ForwardScan
Mast Mounted B&G Nemesis Display
B&G Outside Temp Sensor
B&G Barometric Sensor
Two additional wireless VHF handsets H60 connected to V100 VHF.
Peplink Internet 4G System
Mini VSAT, KVH TracPhone V30
Stereo System (inc upgrade to 4 speakers in saloon and sub woofer)
Cockpit Speakers
Additional Thruster Control - Port Pedestal
Additional Engine Control - Port Pedestal
RigHall Spars Carbon Mast and Boom (Mast ramp for main sail in carbon instead of standard aluminium)
EC-3 Carbon Rigging
Aramid runners with deck blocks and rope tails
Self Tacking System for Staysail
Seldén Electrical Jib Furler TD404E 24 volt
Staysail Hydraulic Tensioner
Captive Mainsheet Winch Harken 3T electric
24v Outlet on mast bracket
Lazy Jacks through Spreaders
Two additional pad eyes in Boom
Boom Set-up for Third Reef
Mastwalkers
Padeyes on mast for safety clips
Padeye on mainsheet island for emergency mainsheet
Painting of Mast Antennas (Radar, AIS, VSAT, 4G, Fog Horn)
Upgrade of standard running rigging to DSK78 RACE KP & RACE NTP. Including jammers with ceramic coated jaws
Boom parking strops
Bars for ropes in sail locker
Spare sheets and lines
SailsFull Batten Mainsail 3Di OCEAN 700 29,400 Dpi 112m
Furling Jib 3Di OCEAN 700 29,400 Dpi 79m
Selftacking Furling Jib 3Di OCEAN 700 29,400 Dpi 36m
InteriorTowel Hooks in all bathrooms
Leather Mast Wrap Silk Cognac SIL 0250
Director Chairs in Leather Silk Cognac SIL 0250
Trim in Bookshelf by Nav Station
Cutlery Dividers
Storage for crockery and glassware
Marine Safe under Saloon Seats
Mirror above desk in owners cabin
Owners headboard in leather  Silk Cognac SIL 0250
Swing-out stool in leather Silk Cognac SIL 0250
Full length mirror on bulkhead in owners cabin
Locker under desk in owners cabin instead of foldout stool
Shower baskets in owners cabin
Storage unit under sink
7 x throw pillows for saloon
Leather pockets in master Silk Cognac SIL 0250
Aft Port Toilet converted to Workshop and Storage for Tools etc
Dive bottle storage in Forepeak
Tender and OutboardDinghy handling system including electrical dinghy winch with wired remote control
TruKit 2.8m cameraman tender with lifting points, cover and beach wheels. Padeyes on deck for storage
6hp 4 Stroke Yamaha Outboard
Storage bracket in Forepeak for Outboard
Convert LGP Locker to Fuel Storage
Safety EquipmentJonbuoy GL Recovery Module Mark 5
Modify Pushpit for Jonbouy
Ocean 6V ISO9650 Liferaft
Ocean Signal EDF1 Electronic Flare - LED
Full set of open water flares
Jonbuoy Glow Lite Horseshoe - Black Case
Jonbuoy GL Danbuoy c/w Light
Petzl Falcon Mountain Climbing Harness
Harken Harness
Fog Horn & Cannister Set
Softwood Plug Set (Large)
V-Tronix Shorelink Emergency VHF Antenna
Ocean Signal RescueME EPIRB3
Ocean Signal EPIRB3 PRO, C/W AIS & RLS and auto release housing
Life jackets x 6
Lifelines on deak and in cockpit
Emergency high volume portable bilge pump
Tools and SparesFull set of tools including battery powered grinder and drill
Main engine spares
Genset spares
Watermaker spares
Tapes, glues, lubricants etc
Internal FitoutAll bed linens, mattresses toppers, pillows
All crockery, pots pans, cutlery
Glassware
Bathroom towels
Storage solutions in cupboards and drawers
Mechanical hoursMain engine - approximately 280 hours Main engine last serviced at 200 hours.   Generator - approximately 120 hours.

Generator last serviced at 40 hours.  Nicolle Associates offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice. This vessel is VAT not paid.
As always photographs do not do justice so a viewing is highly recommended.
This boat is lying in Badalona, Spain.
